Lamps & Lighting Electronics Catalogue 2014

109 / 272

>
MASTER MHN-FC
D
L
O
A
C
X
Dim. A C D L O X
no. nom. max. nom. nom. nom. nom.
1 226 290 25.5 144 42.5 58
2 290 357 25.5 177 108.0 58
Product Description
•Compact quartz metal halide lamps with
double pinch
Product Benefits
•Allows compact luminaire systems with
precision optics for minimal light spill
•Good colour rendering creates a pleasant
ambience with high visual comfort for
players and spectators
•Continuous spectral distribution o ers
options for semi-professional stadiums
and professional stadiums with regular TV
coverage
Product Features
•Double-pinch concept results in long lifetime
•Choice of 1,000 W and 2,000 W types
•Natural white colour appearance
•Compact light source allows small luminaire
design
Environment
•This product is RoHS compliant
•This product is covered by WEEE
Application
•Recreational sports and area floodlighting
Warnings and Safety
•Use only in totally enclosed luminaire,
even during testing (IEC 61167, IEC 62035,
IEC 60598)
•The luminaire must be able to contain hot
lamp parts if the lamp ruptures
MASTER MHN-FC Double Ended Clear
Wattage/
Colour Code
Voltage Lamp
Luminous
Flux EM
Life to 10%
failures
Life to 50%
failures
Burning
Position
Dim.
no.
Packing
type/
Packing
configu-
ration
National Order Code Ordering
number
8711500...
(V) (lm) (h) (h)
1000W/740 230 93,000 8,000 12,000 p5 A+ 1 NO / 1 1 MHNFC1000W740 21424900 yes
2000W/740 400 210,000 8,000 14,000 p5 A+ 2 NO / 1 1 2000MHNFC740 21349500 yes
MASTER MHN-SB
D
O
A
C
X
A C D O X
nom. max. max. nom. nom.
157 188 39 25 50
Optimal beam control, compact design
Compact quartz metal halide lamp with single
pinch
Product Benefits
•Allows compact and e cient luminaire
systems with precision optics for good beam
control and minimal light spill
•Long lifetime and high reliability in Short
Base outer dimensions to minimize service
needs and maintenance costs
•Good colour rendering for a pleasant
ambience with high visual comfort
Product Features
•Compact source (Short Base lamp dimen-
sions) with short electrode distance and high
luminous e cacy
•Single pinch concept with long lifetime
•Natural white colour appearance, good
colour rendering and stability
•Daylight colour temperature eases transition
from daylight to artificial lighting
Application
•Semi-professional sports, area and
floodlighting
Warnings and Safety
•Use only in totally enclosed luminaire,
even during testing (IEC 61167, IEC 62035,
IEC 60598)
•The luminaire must be able to contain hot
lamp parts if the lamp ruptures
More data see next page
Philips Lamps and Lighting Electronic Catalogue 2014 109
06
