MASTER HPI Plus
D
C
Dim. C D
no. max. max.
1 226 91
2 284 122
3 290 122
Product Description
•Quartz metal halide lamps with opalized
outer bulb
Product Benefits
•High safety and comfort level, maintained
over life
•Minimal maintenance cost
•Initial investment saving options with
"Plus"-concept and "S" and "P"-types
•Adjustable atmosphere creation by using
appropriate colour temperature
Product Features
•Ovoid, internally white coated outer bulb
•Unique 3-band technology resulting in high
luminous e cacy, both initially and over long
lifetime
•Available in cool white and daylight colour
appearance demonstrating good colour
stability
•"S"-type for direct retrofit for HPL lamps
•"P"-type for use without protective front
shield
Environment
•Good environmental choice because of long
service life
•This product is RoHS compliant
•This product is covered by WEEE
Application
•High bay lighting, e. g. industrial workshops,
exhibition halls, hypermarkets, shopping
malls, DIY stores, churches, airports and
train stations
Warnings and Safety
•Use only in totally enclosed luminaire,
even during testing (IEC 61167, IEC 62035,
IEC 60598)
•The luminaire must be able to contain hot
lamp parts if the lamp ruptures
•For use with control gear designed for
high-pressure mercury or sodium lamps
MASTER HPI Plus GES Coated
Wattage/
Colour Code
System
Description 1
Luminous
Flux EM
25°C, Rated
Life to
10%
failures
Life to
50%
failures
Burning
Position
Dim.
no.
Packing
type/
Packing
configu-
ration
National Order
Code
Ordering
number
8711500...
(lm) (h) (h)
250W/645 BU 18,000 7,500 20,000 h15 A 1 1SL / 12 12 250HPIPLUSBU 181145 15 yes
250W/645 BU-P 18,000 7,500 20,000 h15 A 1 1SL / 12 12 250HPIPLUSBUP 211477 15 yes
250W/667 BU 18,000 7,500 20,000 h15 A 1 1SL / 12 12 250HPIPLUSDBU 207395 15 yes
400W/645 BU 32,500 7,500 20,000 h15 A+ 2 1SL / 6 6 400HPIPLUSBU 182524 10 yes
400W/645 BU-P 32,500 7,500 20,000 h15 A+ 3 1SL / 6 6 400HPIPLUSBUP 211439 10 yes
400W/667 BU 32,500 7,500 20,000 h15 A+ 3 1SL / 6 6 400HPIPLUSDBU 207371 10 yes
400W/645 BUS 32,500 7,500 20,000 h15 A+ 3 1SL / 6 6 400HPIPLUSBUS 181114 10 yes
400W/645 BUS-P 32,500 7,500 20,000 h15 A+ 3 1SL / 6 6 400HPIPLUSBUSP 211453 10 yes
1 ’ System Description’ value abbreviations: ’BU’ = Base-Up, ’BU-P’ = Base-Up/Protected, ’BUS’ = Base-Up/internal Starter, ’BUS-P’= Base-Up/internal Starter/Protected
HPI-T
Product Description
•Quartz metal halide lamps with clear outer
bulb
Product Benefits
•High safety and comfort level, maintained
over life
•Minimal maintenance cost
Product Features
•Clear tubular outer bulb
•Unique 3-band technology resulting in high
luminous e cacy, both initially and over long
lifetime
•Renders a natural white colour appearance
and good colour stability
Environment
•This product is RoHS compliant
•This product is covered by WEEE
Application
•Sports lighting, floodlighting of buildings and
monuments, area lighting e. g. harbours and
building sites
Warnings and Safety
•Use only in totally enclosed luminaire,
even during testing (IEC 61167, IEC 62035,
IEC 60598)
•The luminaire must be able to contain hot
lamp parts if the lamp ruptures
•For use with control gear designed for
high-pressure mercury lamps
