MASTER CityWhite CDO-ET
D
C
Dim. C D
no. max. max.
1 156 71
2 186 76
3 227 91
The easiest switch to comfortable white light
Ceramic metal halide lamp, with opalized
ovoid outer bulb shape, used in outdoor
o ering pleasant white light
Product Benefits
•White warm colour impression providing
comfort and safety
•Easy upgrade from SON to white light
without additional cost
•Flexible light levels and reduced energy
consumption possible via dimming option
Product Features
•High-quality white light
•Directly retrofit on HPS (SON/NAV)
installations for upgrade from yellow to
white light
•"Plus" concept with high e cacy translates
into high light output and improved lumen
maintenance
•Good colour rendering and harmonized
warm white colour temperature
•Dimmable
Environment
•Good environmental choice because of high
energy e ficiency in white light
•Products are RoHS compliant
•Products are covered by WEEE
Application
•Beautification and functional lighting for City
centers, shopping centers and pedestrian
areas, residential areas, road lighting and
floodlighting
Warnings and Safety
•Use only in totally enclosed luminaire,
even during testing (IEC 61167, IEC 62035,
IEC 60598)
•The luminaire must be able to contain hot
lamp parts if the lamp ruptures
•Lamps may use electronic or electromag-
netic control gear
•Control gear must include end-of-life
protection (IEC 61167, IEC 62035)
MASTER CityWhite CDO-ET Plus Coated
Wattage/
Colour Code
Cap-
Base
Luminous
Flux EM
25°C, Rated
Life to 10%
failures
Life to 50%
failures
Burning
Position
Dim.
no.
Packing
type/
Packing
configu-
ration
National Order Code Ordering
number
8718291...
(lm) (h) (h)
50W/828 ES 5,150 12,000 20,000 any A+ 1 1SL / 24 24 50CDOETPLUS828 18563500 yes
70W/828 ES 7,230 12,000 27,000 any A+ 1 1SL / 24 24 70CDOETPLUS828 15875200 yes
100W/828 GES 9,400 18,000 27,000 any A+ 2 1SL / 12 12 100CDOETPLUS828 15877600 yes
150W/828 GES 15,100 20,000 27,000 any A+ 3 1SL / 12 12 150CDOETPLUS828 15881300 yes
