MASTERColour CDM-T Elite MW
D
L
C
O
Dim. C D L O
no. nom. nom. nom. nom.
1 186 28 90 12.1
2 186 28 90
3 186 28 90 16.0
4 186 28 90 14.0
5 193 38 90 12.1
6 193 38 90
7 193 38 90 16.0
8 193 38 90 14.0
Perfect sparkle, reliable life
The medium wattage lighting system that
gives superior, longer-lasting white light for
both indoor and outdoor use
Product Benefits
•High quality sparkling white light
•Highest energy saving and lowest cost of
ownership
•Reduced energy consumption/CO2
emission
•Dimmable
Product Features
•Very high-quality white light with excellent
colour rendering
•Long reliable lifetime combined with highest
system e cacy
•New socket design makes lamp extremely
compact and improves e ciency
•New electronic gear platform
Environment
•Excellent environmental choice because of
high energy e ciency and long reliable life
•This product is a Philips Green Flagship
•This product is RoHS compliant
•This product is covered by WEEE
Application
•Outdoor; floodlighting of buildings and other
interesting structures. Illumination of roads
and pedestrian areas, public spaces, car
parks, petrol stations etc.
•Indoor; larger (high-bay) retail outlets,
warehouses, manufacturing facilities etc.
Warnings and Safety
•Use only in totally enclosed luminaire, even
during testing, except for protected versions
with PGZX18 cap, which are designed
for open luminaires (IEC 61167, IEC 62035,
IEC 60598)
•The luminaire must be able to contain hot
lamp parts if the lamp ruptures
•Use only with electronic control gear
•Control gear must include end-of-life
protection (IEC 61167, IEC 62035)
MASTERColour CDM-TMW Elite Clear
Wattage/Colour
Code/Feature
Cap-Base Lamp
Luminous
Flux EL
Life to
10%
failures
EL
Life to
50%
failures
EL
Burning
Position
Dim.
no.
Packing
type/
Packing
configu-
ration
National Order
Code
Ordering number
(lm) (h) (h)
210W/930 PGZ18 24,150 14,000 27,000 any A+ 1 1CT / 12 12 210CDMTELITE930 8718291139508 00 yes
210W/942 PGZ18 23,000 15,000 30,000 any A+ 2 1CT / 12 12 210CDMTELITE942 8718291139522 00 yes
315W/930 PGZ18 38,700 16,000 30,000 any A+ 3 1CT / 12 12 8718291548010 00
315W/930 PGZ18 38,700 16,000 30,000 any A+ 3 1CT / 12 12 315CDMTELITE930 8727900801576 00 yes
315W/942 PGZ18 35,500 16,000 30,000 any A+ 4 1CT / 12 12 315CDMTELITE942 8718291548034 00 yes
210W/930W - P PGZX18. 23,300 15,400 21,000 any A+ 5 1CT / 12 12 8718291139546 00
210W/942W - P PGZX18. 22,800 12,000 20,000 any A+ 6 1CT / 12 12 210CDMTPELIT942 8727900862119 00 yes
315W/930W - P PGZX18. 36,200 11,500 20,000 any A+ 7 1CT / 12 12 315CDMTPELIT930 8718291139560 00
315W/942W - P PGZX18. 34,300 13,300 20,000 any A+ 8 1CT / 12 12 315CDMTPELIT942 8718291139607 00
