Connecting and earthing
bars for use with
ESP WT protectors (see
pages 248-249).
Description Part No.
For use with 3 x ESP 690/12.5/WT for TN-C supplies ESP CE7
For use with 3 x ESP 690/25/WT for TN-C supplies ESP CE9
For use with 4 x ESP 690/12.5/WT for TN-S supplies ESP CE10
For use with 4 x ESP 690/25/WT for TN-S supplies ESP CE13
Use to test the ESP SSI/M
protector. See pages 252-253.
ESP PTE002 has Network Rail
Approval PA05/02216. NRS PADS
reference 094/020033.
Annual calibration is required,
which is processed as
ESP PTE002/CAL.
Description Part No.
SSI Portable Tester ESP PTE002
Description Voltage Part No.
Gas Discharge Tube 90 V ESP RF GDT-1
Gas Discharge Tube 150 V ESP RF GDT-2
Gas Discharge Tube 230 V ESP RF GDT-3
Gas Discharge Tube 350 V ESP RF GDT-4
Gas Discharge Tube 470 V ESP RF GDT-5
Gas Discharge Tube 600 V ESP RF GDT-6
Replacement Gas Discharge
Tubes for use with standard RF
protectors. See pages 258-259.
Replacement Gas Discharge Tube
for use with the ESP RF 111A11,
ESP RF AA1A11 and
ESP RF 441A11 protectors
(pages 260-261).
Description GDT Voltage Part No.
Gas Discharge Tube 600 V ESP RF GDT-A
Accessories
ESP RF GDT-x
Connecting and earthing bar
ESP PTE002
Base and module replacements
for the Slim Line Series of
protectors (see pages 212-219,
228-231).
Slim Line replacement base/module
Use with any ESP RF
protector to assist
installation.
See pages 258-261.
Description Part No.
Straight Mounting plate ESP RF BK1
90º Mounting plate ESP RF BK2
Bulkhead through mounting plate (single) ESP RF BK3
Bulkhead through mounting plate (4 protectors) ESP RF BK4
ESP RF mounting plates
Description Part No.
Slim Line protector replacement base
For use with standard and 4-20 mA Slim Line Series ESP SL/B
Isolated screen version for use with standard and
4-20 mA Slim Line Series
ESP SL/I/B
For use with Slim Line Intrinsically Safe (ATEX) Series ESP SLX/B
Isolated screen version for use with Slim Line
Intrinsically Safe (ATEX) Series
ESP SLX/I/B
For use with Slim Line 3-wire Series ESP SL/3W/B
For use with Slim Line RTD Series ESP SLRTD/B
For use with Slim Line RS485 Series ESP SL RS485/B
Slim Line protector replacement module
For use with Slim Line Series - replace ‘XX’ with
relevant voltage, i.e. 06, 15, 30, 50, 110
ESP SLXX/M
For use with Slim Line TN Series ESP SLTN/M
For use with Slim Line Instrinsically Safe (ATEX)
Series, 15 V
ESP SL15X/M
For use with Slim Line Instrinsically Safe (ATEX)
Series, 30 V
ESP SL30X/M
For use with Slim Line RTD Series ESP SLRTD/M
For use with Slim Line RS485 Series ESP SLRS485/M
Slim Line LED protector replacement module
For use with Slim Line LED Series - replace ‘XX’ with
relevant voltage, i.e. 06, 15, 30, 50, 110
ESP SLXXL/M
For use with Slim Line LED Series, 4-20 mA ESP SL30L/4-20/M
For use with Slim Line Instrinsically Safe (ATEX) LED
Series, 15 V
ESP SL15XL/M
For use with Slim Line Instrinsically Safe (ATEX) LED
Series, 30 V
ESP SL30XL/M
For use with Slim Line 3-wire LED Series – replace
‘XX’ with relevant voltage, i.e. 06, 15, 30, 50, 110
ESP SLXX/3W/M
NEW
NEW
