Furse Total Solution to Earthing & Lightning Protection

263 / 300

TSC-0912 - 09.10.12
Tough polycarbonate enclosures (except ABS WBX 2/G)
Weatherproof with IP resistance to dirt and water of IP56 or more
Clear lid enables easy visual inspection of the protector’s visual status
indication (WBX 3, WBX 4, WBX D4, WBX 8, WBX D8, WBX M2, WBX M4)
Grey lid for applications not needing regular protector inspection
(WBX 2/G, WBX 3/G, WBX 4/GS, WBX 8/GS and WBX 16/2/G)
For external CCTV and other installations requiring added security the
WBX 4/GS and WBX 8/GS are supplied with an opaque lid and special
secure head screws (plus tool)
Supplied complete with metal base (mounting) plate with pre-prepared
mounting positions and fixing hardware for easy installation (except
WBX 2/G which has a plain metal base)
Features and benefits
A range of moisture and dirt resistant enclosures for the convenient
installation of ESP protectors and their associated CME with grey
base and either a see-through or grey (part number /G or /GS) lid.
Furse, Wilford Road, Nottingham, NG2 1EB • Tel: +44 (0)115 964 3700 • Email: • Web:
WBX Series
If you’ve got . . . . . . use this enclosure
1 ESP M4 series protector WBX M4
1 CME 4 and associated protectors WBX 4 or the secure WBX 4/GS
1 CME 8 and associated protectors WBX 8 or the secure WBX 8/GS
1 or 2 CME 16 and associated protectors WBX 16/2/G
1 or 2 single earth stud protectors WBX 2/G
up to 3 single earth stud protectors WBX 3/G
1 double earth stud protector WBX 3/G
Specification
If you’ve got . . . . . . use this enclosure
1 ESP 240 or 415/XXX/TNS or TNC protector, or
single phase D1 series protector
WBX D4
1 ESP 415/XXX/TT protector, or three phase D1 series
protector
WBX D8
1 single phase M1 series protector WBX 3
1 three phase M1 series protector WBX 4
1 ESP M2 series protector WBX M2
WBX 2/G WBX 3
WBX 3/G
WBX 4
WBX 4/GS
WBX D4 WBX 8
WBX 8/GS
WBX D8 WBX 16/2/G WBX M2 WBX M4
Weight - unit
- packaged
0.45 kg
0.5 kg
0.5 kg
0.55 kg
0.9 kg
0.95 kg
0.4 kg
0.45 kg
1.3 kg
1.35 kg
0.55 kg
0.6 kg
6.4 kg
7.6 kg
1.9 kg
2.3 kg
2.2 kg
3.0 kg
Dimensions
Length - internal
- external
150 mm
160 mm
222 mm
230 mm
225 mm
235 mm
-
200 mm
225 mm
235 mm
-
200 mm
460 mm
474 mm
254 mm
280 mm
254 mm
280 mm
Width - internal
- external
110 mm
120 mm
72 mm
80 mm
150 mm
160 mm
-
123 mm
225 mm
235 mm
-
195 mm
380 mm
396 mm
254 mm
280 mm
254 mm
280 mm
Depth - internal
- external
71 mm
90 mm
79 mm
85 mm
100 mm
117 mm
-
112 mm
100 mm
117 mm
-
112 mm
120 mm
128 mm
115 mm
130 mm
165 mm
180 mm
Fixing centres (mm) 148 x 90 210 x 60 215 x 140 140 centrally 215 x 215 140 x 88 380 x 310 254 x 254 254 x 254
IP rating IP66 IP67 IP66 IP65 IP66 IP65 IP56 IP67 IP67
Use WBX enclosures when your
ESP protector(s) can’t be installed
within the existing equipment
panel or enclosure and for added
protection in damp and dirty
environments.
For additional enclosure options,
please contact us.
Application
For added security, /GS versions
(e.g. WBX 4/GS) are supplied with an
opaque lid and optional secure
head screws (plus tool)
The protector(s), or CME kit, are
mounted on the metal base plate,
which in turn mounts in the
enclosure.
Installation
