Network Infrastructure
SPECIFICATIONS
Operating voltage . . . . . . . . . . .24 V AC ±20%, 50/60 Hz or 19–40 V DC
Power consumption . . . . . . . . . .max. 5 W
Transformer sizing . . . . . . . . . . .5 VA
Dimensions. . . . . . . . . . . . . . . . .90 x 110 x 77mm (3.5” x 4.3” x 3”)
Enclosure rating . . . . . . . . . . . . .IP 20
Real Time Clock
Accuracy at +25°C (77º F) . . . . .±12 minutes per year
Power failure protection. . . . . . .72 h
Ambient Temperature
Storage. . . . . . . . . . . . . . . . . . . .–20°C to +50°C (–4°F to +122°F)
Operation . . . . . . . . . . . . . . . . .0°C to +50°C (+32°F to +122°F)
Humidity . . . . . . . . . . . . . . . . . .max. 90% RH non-condensing
Communication
A: RS232 . . . . . . . . . . . . . . . . . .2400 – 57600 bps, RJ45, 8-p
A: RS485 . . . . . . . . . . . . . . . . . .2400 – 57600 bps, async. terminal block
B: RS232 . . . . . . . . . . . . . . . . . .RJ10, 4-p
C: RS485 . . . . . . . . . . . . . . . . . .sync. (SDLC) terminal block
L
ON
W
ORKS
®
. . . . . . . . . . . . . . . . .TP/FT-10, terminal block
Ethernet . . . . . . . . . . . . . . . . . . .TCP/IP, 10Base-T, RJ45
TAC Xenta 913
L
ON
W
ORKS
®
/INET Gateway (continued)
EIA-709 Network Interface with MNI (multiplexed network interface)
Supports FT-10, TP-1250/2500, RS-485
Connects to the PCI bus of a PC
Compatible with LNS, MIP, and ORION applications
NIC-PCI
Network Interface
DESCRIPTION
9-073-0066-0 LON
®
Network Interf.(NIC709-PCI)
DESCRIPTION
0-073-0835-1 TAC Xenta 913
ACCESSORIES
0-073-0902-0 Terminal part TAC Xenta 400
0-073-0920-0 TAC Xenta: Programming Serial Kit
