Transceiver
1
x 100BASE-TX port
RJ45
Shielded twisted pair, category CAT 5E
100
m
1
x 100BASE-FX port
SC
Multimode optical fibre
3000
m
(1)
3000
m
(1)
8
dB
11
dB
–
–
P1 and P2 redundant power supplies
24
V
c
(18…32)
safety extra low voltage (SELV)
160
mA (190 max. at 24 V
c
)
5
terminals
0…
+ 60°C
10…95%
non-condensing
IP 20
47
x 135 x 111 mm
On symmetrical DIN rail, 35 mm wide
0.230
kg
cUL 60950, UL 508 and CSA 22.2 No. 142, UL 1604 and CSA 22.2 No. 213 Class 1 Division 2,
e
,
GL, C-Tick
P1 and P2 power supplies, Ethernet link/port status
Power supply fault, Ethernet network fault or communication port fault (volt-free contact 1 Amax. at 24 V
c
)
499
NTR 101 00
5/68
(1)
Length dependent on the attenuation analysis and attenuation of the optical fibre (typical value: 2000 m).
