Device type
Unmanaged switches, copper twisted pair
Interfaces
Copper cable ports Number and type
5
x 10BASE-T/100BASE-TX ports
8
x 10BASE-T/100BASE-TX ports
Shielded connectors
M12 (type D)
RJ45
Medium
Shielded twisted pair, category CAT 5E
Total length of pair
100
m
Fibre optic ports
Number and type
–
Connectors
–
Medium
–
Length of optical fibre 50/125 μm
–
62.2/125
μm
–
Optical fibre
attenuation analysis
50/125
μm fibre
–
62.2/125
μm fibre
–
Ethernet services
Storage and re-routing of received data,
auto MDI/MDX, automatic negotiation of
10/100
Mbps and duplex mode (on all ports)
–
Topology
Number of switches Cascaded
Unlimited
Redundant in a ring
–
Redundancy
–
P1 and P2 redundant power supplies
Power supply
Voltage
24
V
c
(18…32)
safety extra low voltage (SELV)
Consumption
100
mAmax.
125
mA (290 mAmax.)
Removable terminal block
5
terminals, M12 (type A, male)
5
terminals
Operating temperature
0…
+ 60°C
Relative humidity
–
10…95%
non-condensing
Degree of protection
IP 67
IP 20
Dimensions
W x H x D
60
x 126 x 31 mm
47
x 135 x 111mm
Mounting
On a flat surface
On symmetrical DIN rail, 35 mm wide
Weight
0.210
kg
0.230
kg
Conforming to standards
cUL 508 and CSA 22.2 No. 142
cUL 60950, UL 508 and CSA 22.2 No. 142,
UL 1604 and CSA 22.2 No. 213 class 1
division 2,
e
,
GL, C-Tick
LED indicators
Power supply, link status, data rate
P1 and P2 power supplies, Ethernet link/port
status
Alarm relay
–
Power supply fault, Ethernet network fault or
communication port fault (volt-free contact 1 A
max. at 24 V
c
)
Reference
TCS ESU 051F0
499
NES 181 00
