Standalone Web Gateway/Server modules for remote access
FactoryCast Gateway ETG 10
p
0
FactoryCast HMI Gateway ETG30
pp
All equipment supporting
Uni-Telway
All Modicon PLCs and third-party equipment supporting Modbus
Intranet or Modem, External Modem and integrated RAS function
Intranet or Modem
RTC modem and integrated RAS function
Intranet or Modem
GSMmodemand integrated RAS function
Remote programming, downloading via FTP, access to Web server via web browser
Ethernet to Uni-Telway serial
Modem to Uni-Telway and Ethernet
Ethernet to Uni-Telway serial, Modem to Modbus serial and Ethernet
Uni-Telway slave
Modbus master
Modbus/TCP
Uni-TE (Premium, Micro)
Modbus/TCP
BootP/DHCP, DNS, SNMP agent,
SMTP client, NTP client
(2)
,
FTP
DHCP, DNS, SNMP agent, SMTP client, NTP client
(2)
,
FTP
Protection by IP address filtering and passwords
HTTP and FTP server, 8MBmemory
available for user, hosting of user Web
pages and docs (Doc, Pdf, Excel)
HTTP and FTP server, 32 MB memory available for user Web pages, memory expansion using Compact Flash cards 1 Gb
max., hosting of user Web pages and documents (Doc, Pdf, Excel)
Via Web Designer software or predefined Web pages
Serial device diagnostics via
predefined Web pages
Network diagnostics, serial and Ethernet device diagnostics via predefined Web pages
Monitoring of devices and application via animation tables (read/write variables)
Display of PLC Unity program in a Web page
–
Graphic monitoring via animated views (integrated graphic editor)
–
Graphic monitoring via animated Web pages created by the user
Arithmetic and logical scripts
Alarm notification by e-mail
Alarm notification by e-mail / SMS
–
Data recorded in the module with date and time stamping (CSV files)
–
Direct recording in an SQL, Oracle or MySQL server
–
Dynamic HTML report management
–
Management of “Recipe”data (storage and review locally or on remote database)
Web Designer (supplied with each module)
TSX ETG1010
TSX ETG3000
TSX ETG3010 (PSTN modem)
TSX ETG3021
(
GSM 900/1800 MHz band)
TSX ETG3022 function
(
GSM 850/1900 MHz band)
www.schneider-electric.com(2)
Except with
TSX P57 103M/153M
processors which do not have the NTP service.
WebDesigner
