Selection guide
(
continued)
Modicon Premium automation
platform
0
Bus modules
Applications
Network type
Open industrial fieldbus compliant with the
FIP standard
Uni-Telway serial link
Type
Fipio (agent)
Fipio
(
bus manager)
Uni-Telway
Structure
Physical interface
FIP standard
Non-isolated RS 485 Isolated RS 485
Access method
Bus managed by bus arbitrator
Master/slave
Data rate
1
Mbps
19.2
Kbps max.
Medium
Twisted pair
Fibre optic via transmitters or repeaters
Double shielded twisted pair
Configuration
Number of devices
32
per segment
128
for all segments (limited to 64 with
TSX P57 1
p
processor)
5 (
excluding
programming
terminal)
28,
96
slave addresses
max.
Max. length
1000
m to 15,000 m (depending on the
medium used) with repeaters
10
m
1000
m
Number of links/station
1
max.
1
max.
64
max. depending
on processor and
application-specific
channels used
Services
Message handling
Uni-TE:
-
Periodic data exchange (Agent function)
-
Application to application
-
Transparent exchange of remote I/O
Uni-Telway :
-
Uni-TE message handling 240 bytes
-
Client/server
-
Application to application 240 bytes
-
Transparency of all devices on X-Way
architecture via a master
Processor type
All types of Premium
processor
TSX P57
p
53
M/54M
TSX P57
p
823
M
All types of Premium processor
Module type
PCMCIA type III card
on Premium
processor
Integrated link on the
Premium processor
Integrated
Uni-Telway link
Standard format
module
Consumption
–
See page 9/6
Standards and certifications
See pages 9/8 to 9/18
Module type
TSX FPP 10
Integrated link
on processor
TER and AUX
terminal port
TSX
SCY 21601
Pages
5/105
5/103
5/130
