137 / 413
5/3
Ethernet Modbus/TCP modules
EtherNet/IP and Modbus/TCP
module
Ethernet Modbus/TCP
EtherNet/IP andModbus/TCP
10
BASE5 (AUI), 10BASE-T 10BASE-T, 100BASE-TX (RJ45)
CSMA-CD
10
Mbps
10/100
Mbps
Triaxial cable or CAT 5E
double twisted pair cable
Fibre optic via Ethernet
ConneXium cabling system
CAT 5E double twisted pair cable
Fibre optic via Ethernet ConneXium cabling system
64
stations maximum per network
128
stations maximum per
network
100
m (copper cable), 4000 m (multimode optical fibre), 32,500 m (single mode optical fibre)
1
to 4 depending on processor used
–
Modbus/TCP and Uni-TE message handling
Modbus/TCP and EtherNet/IP
message handling
X-Way inter-network routing, X-Way/Uni-Telway routing, module diagnostics
–
Uni-TE message handling,
common words, applic. to
application
–
–
C10
B30
C30
D10
–
Rack Viewer PLC diagnostics
Data Editor access to PLC data and variables
Alarms Viewer
Graphic Data Editor
Display of user Web pages
(1.4
Mb available)
–
Alarms Viewer
Graphic Data Editor
Display of user Web pages (8 Mb available)
–
–
FactoryCast HMI services
(2) –
–
Yes (between 64 stations)
–
Yes (between 128 stations)
–
Yes
–
–
Yes (automatic assignment of IP address and network
parameters)
–
Yes (automatic assignment of
IP address and network
parameters)
–
Yes
–
–
Yes (via Unity Pro function blocks)
Yes (active Web server)
–
SNMP agent
–
Server
Client/server
Option
–
Option
–
–
Yes
–
–
Yes
All types of Premium processors
TSX P57 1
p
/
P57 2
p
/
P57 3
p
/
P57 4
p
/
P57 5
p
/
P57 6
p
Standard format module
See page 9/6
See pages 9/8 to 9/18
TSX ETY 110 WS
TSX ETY 4103
TSX ETY 5103
TSX WMY 100
TSX ETC 101
5/47
5/49
(2)
FactoryCast HMI services: HMI database, automatic e-mail notification of events, interpreted math and logic functions, connection to relational databases and
simulator tool for debugging.
