5/4
Selection guide
(
continued)
Modicon Premium automation
platform
0
Network and bus modules
Applications
Industrial LAN compliant with the Modbus
Plus standard
Industrial LAN compliant with the
Fip standard
Type
Modbus Plus
Fipway
Structure
Physical interface
Modbus Plus standard
RS 485
WorldFip standard
Devices connected by daisy-chaining
or tap junctions
Access method
Token ring
Bus managed by bus arbitrator
Data rate
1
Mbps
1
Mbps
Medium
Twisted pair
Fibre optic
Twisted shielded pair
Fibre optic via transmitters or repeaters
Configuration
Number of devices
32
per segment
64
on all segments
Maximum length
450
m per segment
1800
m with 3 repeaters
1000
m per electrical segment
5000
m max. with repeaters
Number of links/station
1
max.
1
to 4 depending on processor model
Services
Message handling
Modbus Plus message handling:
-
Reading/writing variables
-
Global database
-
Peer Cop service
-
Uni-TE
-
Shared COM/table
-
Application to application
-
Telegram
Processor type
All types of Premium processor
Module type
PCMCIA type III card on Premium processor
PCMCIA type III card on Premium processor
(1)
and on
TSX SCY 21601
module
Consumption
–
Standards and certifications
See pages 9/8 to 9/18
Module type
TSX MBP 100
TSX FPP 20
Pages
5/116
5/107
(1)
Except on
TSX P57 4634M
/
5634
M
/
6634
M
processors with integrated Ethernet port.
