D-80
Additional informations
Two cubicles with busbar compartment, 800 mm
wide, 400 mm deep, IP30
Diversity factor: 0.7 and 0.8
Ambient temperature around the switchboard: 35 °C
Cubicle
1
: P(W) of device zone = 580 W
Cubicle
2
: P(W) of device zone = 180 W
DD383957
Two cubicles with busbar compartment, 800 mm
wide, 1000 mm deep, two 300 mm wide ducts, IP30
Diversity factor: 0.7
Ambient temperature around the switchboard: 35 °C
Cubicle
1
: P(W) of device zone = 880 W
Cubicle
2
: P(W) of device zone = 330 W
DD383886
NSX250
NSX400
NSX NSX NSX NSX
NSX400
NSX NSX NSX NSX
NSX630
