Tools required for mounting
and connection
Additional informations
DD383904
Vacuum cleaner to clean the switchboards
Ratchet wrench with sockets
Torque wrench with sockets and ring bits to tighten the electrical connections to
the correct torque (max. torque 50 Nm)
Open-ended spanners (15 to 27 mm).
Electrician's knife
7, 8, 10, 13, 16, 17 and 19 mm sockets
Bit holder socket
4, 5, 6, 8 and 10 mm hexagonal-head bits
Pozidriv no. 1, 2 and 3 bits
Rubber mallet
Level.
Measurement and inspection tools and instruments
Drill
Semi-circuit nosed pliers
Cable-tie pliers
Wire stripper
Crimping tool
Diagonal cutter
Wire cutters
Flat-nosed pliers
Bit holder for screwdriver
Extension
Electric saw
Jig saw
Clamp for cubicle alignment
Buzzer or tester
3, 5, 4, 5.5 and 8 mm flat screwdrivers
Posidriv no. 2 crosshead screwdriver (to mount handle)
Hydraulic jacks that can be operated in horizontal position to lift cubicles and move
them sideways if necessary.
Coloured, indelible and temperature resistant acrylic varnish.
Electric screwdriver
Note:
a Facom brand torque wrench is available with a capacity of 75 Nm and a thin shape. It is
recommended for tightening under difficult access conditions.
Part numbers:
SP3723 = wrench handle (essential)
SP3721 = extra-flat ratchet adapter (essential)
SP3722 = ratchet for ordinary sockets (optional) for mounting on handle SP3723
SP2709 = extra-flat 13 mm short socket
SP2709A = extra-flat 13 mm long socket
SP4369 = extra-flat 16 mm short socket
SP4370 = extra-flat 16 mm long socket
SP2710 = extra-flat 17 mm short socket
SP4371 = extra-flat 19 mm short socket
SP4372 = extra-flat 19 mm long socket
