A-56
Functional units
Installation
Dd383583
Device
No. of
devices per
row
No. of
vertical
modules
Mounting
plate
Cut-out front
plate
Long terminal
shields
Switch-disconnecteur fuses
INF32/40
1 x 3/4P 3
03540
03313
INF63
1 x 3P
5
03541
03314
49658
1 x 4P
5
03541
03314
49658 x 2
INF100/160
1 x 3P
5
03541
03314
49659 x 6
1 x 4P
5
03541
03314
49659 x 8
INF250
1 x 3P
7
03543
03727
49255 x 6
1 x 4P
7
03543
03727
49255 x 8
INF400
1 x 3P
8
03538
03729
49255 x 6
1 x 4P
8
03538
03729
49255 x 8
Dd383584
INF630
1 x 3P
11
03539
03730
49257 x 6
1 x 4P
11
03539
03730
49257 x 8
INF800
1 x 3P
11
03539
03730
49257 x 6
1 x 4P
11
03539
03730
49257 x 8
Busbar connection
Linergy or flat busbars
Connection made by the customer.
Choice of flexible bars to be used for the connection for INF
y
630 A: see page B-54.
Dd383585
Fupact INF
Horizontal
Extended rotary handle
Fusegear
