A-54
Functional units
Installation
Dd383589
Device
No. of
devices
per row
No. of
vertical
modules
occupied
Mounting
plate
Cut-out
front
plate
Downstream
front plate
Long
terminal
shields (qty
per device)
Fuse-switch disconnectors
ISFT100
(installation
on mounting plate)
5
6
03554 03320
ISFT160
(installation
on mounting plate)
4
6
03556 03321
49869 x 2
ISFT160
(installation
on busbars)
4
6
03555 03321
49869 x 2
ISFT250
(installation
on mounting plate)
2
9
03557 03322
49872 x 2
ISFT160 on mounting plate.
ISFT400
(installation
on mounting plate)
2
9
03557 03323
49875 x 2
ISFT630
(installation
on mounting plate)
1
10
03557 03324 03802
49876 x 2
Accessories
Dd383590
DD382484
Comb busbars for ISFT100
for 2 devices
49861
for 3 devices
49862
for 4 devices
49863
Coupler to connect 2 busbars
49890
Tooth cover
49864
Set of 3 connectors (25 to 95 mm²)
49865
Set of 3 distribution connectors 3 x 10 mm²
49860
ISFT630.
Busbar connection
Linergy or flat busbars
Connection made by the customer.
Choice of flexible bars to be used for the connection: see page B-54.
Connection
Cable-tie supports: see page B-55.
Fupact ISFT
Vertical
3P
Installation on mounting plate or busbars
Fusegear
