Functional units
Connection
Cable connection
Dd383580
Device
Vert. conn.
adapters
Vertical-
connection
adapters
Cable-lug
adapters
Terminal extension
bar support
Interpact INS-INV
INS-INV630b/
1600
3P
31301
33644
4P
31302
33645
INS-INV2000-
2500
3P
33975
04694
4P
33976
04694
Depending on the type of front connection, an INS-INV2000-2500 can be mounted in
a 400 mm or 600 mm deep enclosure.
For rear connection, a 600 mm deep enclosure is required.
INS-INV630b/1600.
Device installation
Dd383581
Device
No. of
modules
Mounting
plate
Cut-out front
plate
Upstream
front plate
Downstream
front plate
Interpact INS-INV
INS-INV630b/
1600
3P 14
03501
03713
03804
03804
4P 14
03501
03714
03804
03804
INS-INV2000-
2500
3P/4P 14
03501
03715
03803
03803
Distribution
Flat or Linergy busbars
Dd383582
Device
Connection
Free supports
Cover for BB
connection
Interpact INS-INV
INS-INV630b/
1600
3P
04481
(Linergy)
04926
(1)
4P
04482
(Linergy)
04926
(1)
INS-INV2000-
2500
3P/4P
must be made
04662
x 2
04926
(1)
(1)
Partitioning of devices must be made.
Selection of Linergy busbars
: see page B-10.
Selection of flat busbars
: see page B-18.
