Aluminium trunking systems
ALUMINIUM TRUNKING SYSTEMS
See
page 177
for quick
reference
chart
174 |
XL 311 to 313 aluminium
Individual covers for
each compartment
XL aluminium trunking 311 to 313 comprises a range of deep,
multi-compartment systems that provide extra capacity and
screening performance levels for data cabling. XL 311, 312 and
313 offer the facility to extend height for higher density cabling.
Product information
•
308 x 65mm
•
4 or more deep segregated compartments
•
Compartments can be subdivided
•
Suitable for dado and skirting applications
(XL 311 is recommended for dado application only)
•
Includes a range of polycarbonate clip-on fittings with
built-in overlaps
•
Fully compatible with Sterling flush power and data accessories
Data information
•
Data compliant 25mm and 50mm bend radius
•
External bends feature internal segregators
•
Adjustable data box 32mm - 47mm
•
Screened divider and data boxes
Base unit
code
pack
ELTB300
2 x 3m
Main compartment cover
code
pack
LTL1SG
1
Angled cover
code
pack
ELAC300SG
1 x 3m
Square cover
code
pack
ELSC300SG
1 x 3m
Trunking profiles
Basic components
*XL 311
size
308 x 65mm
*For dado installation only
XL 312
size
308 x 65mm
XL 313
size
308 x 65mm
Colour code suffix:
to indicate the
finish you require, add the required
colour code to the end of the product
code.
Colour options:
optional colours and
finishes are available but these are
subject to minimumquantity orders
and longer lead times.
For more information contact the
Technical Team on +44 (0)1424 856688.
Part M
For 1 and 2 gang box
assemblies with coloured
flush plates to comply
with Part Mplease
refer to page 106.
Extendable base*
code
pack
ELEB300
1 x 3m
* To increase number of compartments
Standard Colours
WH
SG
WH
: White
SG
: Silver grey
p296
Technical
Information
PAGE
161
