Aluminium trunking systems
ALUMINIUM TRUNKING SYSTEMS
XL 311 to 313 aluminium | 177
Base unit
Pack 2 x 3m
Features earth bonding rail and screw
ports to aid the fastening of pipe clips
and gas valves etc
Extendable base
Pack 1 x 3m
Additional 88mm compartment
Main compartment cover
Pack 1 x 3m
Angled cover
Pack 1 x 3m
Square cover
Pack 1 x 3m
Couplers
Pack 1
End caps
Pack 1
left or right hand
Internal bends
Pack 1
External bends
Pack 1
Flat angles
Pack 1
upward or downward
† Flat tees
Pack 1
† See Flat Tee information below
† XL Trunking 312 flat tees
Where profiles have one angled cover and one square cover, as with
XL Trunking 312, it is possible to create a tee by changing the top or
bottom cover so that covers match the profile of the trunking. For
example:
• Upward tee – select XL 311 tee remove the angled bottom cover
and replace with square cover.
• Downward tee – select XL 313 tee remove the square top cover
and replace with angled cover.
4 Compartment
ELTB300 ELTB300 ELTB300
ELEB300 ELEB300 ELEB300
2 x LTL1SG 2 x LTL1SG 2 x LTL1SG
2 x ELAC300SG 1 x ELAC300SG –
– 1 x ELSC300SG 2 x ELSC300SG
EC401SG &
ELLCC400SG
EC402SG &
ELLCC400SG
EC403SG &
ELLCC400SG
EEC401SG &
ELLEC400SG
EEC402LHSG &
ELLEC400SG
EEC402RHSG &
ELLEC400SG
EEC403SG &
ELLEC400SG
EIB401SG &
ELLIB400SG
EIB402SG &
ELLIB400SG
EIB403SG &
ELLIB400SG
EXB401SG &
ESLEB400SG
EXB402SG &
ESLEB400SG
EXB403SG &
ESLEB400SG
EFA311SG EFA312USG &EFA312DSG EFA313SG
XL 311
308 x 65mm
XL 312
308 x 65mm
XL 313
308 x 65mm
EFT311SG † EFT313SG
p296
Technical
Information
Quick reference chart
XL Aluminium 311 to 313
