Aluminium trunking systems
ALUMINIUM TRUNKING SYSTEMS
178 |
Twin Plus aluminium
Flat angle cover
code
pack
EFAC60SG
1
Standard external
bend cover
code
pack
ESXBC60SG
1
Base unit
code
pack
EMTA60SG
1 x 3m
Main compartment cover
(aluminium)
code
pack
LTL1SG
1 x 3m
End cap
code
pack
EEC60SG
1
Coupler
code
pack
EC60SG
1
Internal bend cover
code
pack
EIBC60SG
1
Basic components
Fittings (ABS)
Accessories can
be fitted in either
compartment
Compartment without accessories
offers extra large data cable capacity
Two large compartments
with permanent segregation
Twin Plus aluminium is an extra deep cable management solution incorporating
two large segregated high capacity compartments. Twin Plus is specifically
designed for carrying large quantities of Cat 6 data cabling.
Product information
•
210 x 57mm
•
2 large permanent segregated compartments
•
Each compartment can be subdivided
•
Suitable for dado and skirting applications
•
Bends angles and tees with a large bend radius
•
Includes a range of clip-on fittings with built-in overlaps
•
Fully compatible with Sterling flush power and data accessories
•
All fittings are ABS
Data information
•
50mm bend radius fittings
•
Adjustable data box 32-47mm
•
Screened divider and data boxes
Screened data outlet
fed from bottom
compartment
Colour code suffix:
to indicate the
finish you require, add the required
colour code to the end of the
product code.
Colour options:
optional colours
and finishes are available but these
are subject to minimumquantity
orders and longer lead times.
For more information contact
the Technical Team on
+44 (0)1424 856688.
Part M
For 1 and 2 gang box
assemblies with coloured
flush plates to comply
with Part Mplease
refer to page 106.
End cap retaining screws
When installing end caps, additional retention
can be achieved by using end cap retaining
screws G1310 (pack 40).
Standard Colours
WH
SG
WH
: White
SG
: Silver grey
