Aluminium trunking systems

ALUMINIUM TRUNKING SYSTEMS

XL 311 to 313 aluminium

| 175

Fittings (Polycarbonate)

Fittings (Aluminium)

XL 311

Coupler

code

pack

EC401SG plus ELLCC400SG

XL 313

Coupler

code

pack

EC403SG plus ELLCC400SG

XL 312

Coupler

code

pack

EC402SG plus ELLCC400SG

XL 311

End cap

code

pack

EEC401SG plus ELLEC400SG

Universal for RH and LH

XL 313

End cap

code

pack

EEC403SG plus ELLEC400SG

Universal for RH and LH

XL 312

End cap

code

pack

EEC402LHSG plus ELLEC400SG

EEC402RHSG plus ELLEC400SG

XL 311

Internal bend

code

pack

EIB401SG plus ELLIB400SG

XL 312

Internal bend

code

pack

EIB402SG plus ELLIB400SG

XL 313

Internal bend

code

pack

EIB403SG plus ELLIB400SG

XL 311

External bend

code

pack

EXB401SG plus ESLEB400SG

XL 313

External bend

code

pack

EXB403SG plus ESLEB400SG

XL 312

External bend

code

pack

EXB402SG plus ESLEB400SG

XL Trunking 312 flat tees

Where profiles have one angled cover and one square cover, as with

XL 312, it is possible to create a tee by changing the top or bottom

cover so that covers match the profile of the trunking. For example:

• Upward tee – select XL 311 tee remove the angled bottom cover and

replace with square cover.

• Downward tee – select XL 313 tee remove the square top cover and

replace with angled cover.

XL 311

Flat angle – up/down

code

pack

EFA311SG

XL 312

Flat angle – upward

code

pack

EFA312USG

XL 312

Flat angle – downward

code

pack

EFA312DSG

XL 313

Flat angle – up/down

code

pack

EFA313SG

XL 311

Flat tee – up/down

code

pack

EFT311SG

XL 313

Flat tee – up/down

code

pack

EFT313SG

End cap retaining screws

When installing end caps, additional retention

can be achieved by using end cap retaining

screws G1310 (pack 40).
