Marshall-Tufflex Cable Management Catalogue

160 / 327

Aluminium trunking systems
167 x 50mm
Dado trunking with three separate
compartments and individual covers
for each compartment. Page
166
167 x 50mm
Skirting trunking with three separate
compartments and individual covers
for each compartment. Page
166
167 x 50mm
Dado and skirting trunking with three
separate compartments and individual
covers for each compartment.
Page
166
160 | Introduction
10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190
All aluminium systems are available with standard powder coat finishes in white RAL
9016 or silver-grey RAL 9006. For other finishes, please call our Technical Team on
+44 (0)1424 856688.
0
280
270
260
250
240
230
220
200
190
180
170
160
150
140
130
120
110
100
90
80
70
60
50
40
30
20
10
210
220 x 65mm
Dado trunking with three
deep compartments.
Page
170
220 x 65mm
Skirting trunking with three
deep compartments Page
170
220 x 65mm
Dado and skirting
trunking with three
deep compartments Page
170
308 x 65mm
Skirting trunking with four
deep compartments. Page
174
308 x 65mm
Dado and skirting
trunking with four
deep compartments. Page
174
308 x 65mm
Dado trunking with four
deep compartments. Page
174
105 x 105mm
Desk and laboratory trunking.
Page
181
210 x 57mm
Large capacity dado and skirting
trunking with two deep compartments
with in-built segregation of power
and data.
Page
178
Note: use the rule on the left of this page to check profile sizes.
110 x 55mm
Dado and skirting trunking with
a single cover. Page
162
170 x 55mm
Dado and skirting trunking with
a single cover. Page
164
