Aluminium trunking systems
ALUMINIUM TRUNKING SYSTEMS
MT32 pre-wired modular accessories
| 161
Adaptor cables 2.5mm²
code
length pack
AA8901
(male/male)
0.5m 1
AA8902
(female/female)
0.5m 1
Required for ring circuit
Extension cable 2.5mm²
code
length
pack
AA3330
0.5m
1
AA3331
1.0m
1
AA3332
1.5m
1
AA3333
3.0m
1
AA3335
5.0m
1
Connection cable
free end 2.5mm²
code
length pack
AA3732
(male)
1.5m
1
AA3532
(female)
1.5m
1
Male and female
adaptors 2.5mm²
code
length
pack
AA7211
(male)
220mm
1
AA7212
(female)
220mm
1
Pre-wired accessories
Terminal block 2.5mm²
code
size pack
AA6510
(female/male)
2.5mm²
1
MT32 Connectors
The description ‘male’ (white) and
‘female’ (black) does not refer to
the connector pins but describes
and identifies the moulded
connector housings.
For further information please
contact our Technical Team on
+44 (0)1424 856688.
Pre-wired accessory 2.5mm²
code
size
pack
AA6221
2 gang
1
W
I
R
I
N
G
S
Y
S
T
E
M
S
MT32
P
R
E
F
A
B
R
I
C
A
T
E
D
MT32 prefabricated andmodular wiring systems are designed to take all the hard
work out electrical installations by providing the complete pre-wired, pre-tested,
plug and play electrical wiring system.
Female shielded
connection
Male shielded
connection
Complete pre-wired
through accessory assembly
incorporating MT32
trunking back box
MT32 is a modular plug and play system designed to simplify electrical
installation of power within perimeter trunking and underfloor
installations. The system provides fast, safe, labour and cost saving
installations that comply with BS 8488:2009+A1:2010 for prefabricated
wiring systems intended for permanent connection in fixed installation.
The range of pre-wired, pre-tested and assembled interconnecting leads
and accessory modules incorporating the Marshall-Tufflex compact
32Amp connector.
Product information
•
32Amp rated system
•
Available as LSOH 3 core 2.5mm² flex system specification that
meets the requirement for high integrity earthing
•
Suitable for ring and radial circuits
•
Circuit testing only required on completion of final layout
•
Reduced installation time – no cutting required on site
•
Reduced health & safety risk
MT32 prefabricated and modular wiring systems
For adapting distribution
board to modular system
Note:
to fit 20mm knockout
p258
