Aluminium trunking systems
ALUMINIUM TRUNKING SYSTEMS
PAGE
161
164 |
Elegance 170 aluminium
Elegance 170 aluminium is a sleek and rounded 170mm
rectangular dado trunking system with a single cover, ideal for
use in office or educational environments where extra mechanical
strength and a higher cable capacity is required.
Product information
•
170 x 55mm
•
“C” type section can be used as a single large compartment
section or can be further subdivided into 2 or 3 compartments
•
Suitable for dado and skirting applications
•
Plain or pre-punched dividers for quick installation
•
A range of fabricated fittings
•
Part M compliant
•
Data compliant 25mm and 50mm bend radius
•
Compatible with Marshall-Tufflex flush power and data
accessories and standard UK wiring power and accessories
•
Standard silver-grey RAL 9006 powder coat finish. White
RAL 9016 is also available to order subject to a lead time.
•
Can be used in conjunction with Conduit and Mini trunking systems
Basic components
Fittings
Can be divided into 2
or 3 compartments
Part M
For 1 and 2 gang box
assemblies with coloured
flush plates to comply
with Part Mplease
refer to page 106.
One cover
Pre-punched
Divider
Options:
optional colours and finishes are available
but these will be subject to minimumquantity
orders, longer lead times and set up charges.
For more information contact the Technical Team
on +44 (0)1424 856688.
Note:
In order to subdivide
Elegance 170 dividing fillets
should be used
Standard Colours
SG
SG
: Silver grey
End cap (screws included)
code
pack
LP1030SG
1
Internal bend 90º
code
pack
LP1020SG
1
External bend 90º Slow
code
pack
LP1026SG
1
Flat angle
code
pack
LP1040SG
1
Flat tee
code
pack
LP1045SG
1
Base unit and cover
code
pack
LP1050SG
1 x 2.9m
p290
Technical
Information
