Boxes and plates
Screened boxes
Conductive spray (CS) is unique to Marshall-Tufflex
and is applied in the factory to provide screening
from electromagnetic interference to data and
communications cabling within trunking systems.
The coating is applied to a range of data boxes,
covers, clip-on components and fabricated fittings.
WARNING
: A CS coating is not suitable for low voltage circuits.
Screening
1 gang screened accessory box
code
depth
description pack
ESSB1SWH*
30mm
PVC-U
20
2 gang screened accessory box
code
depth
description pack
ESSB2SWH*
30mm
PVC-U
10
1 gang adjustable
depth box
code
depth
pack
EAB1SG
32 – 40mm 1
1 gang accessory box
30mm deep
code
description pack
ESSB1SG
ABS
1
ESSB401WH
polycarbonate 1
2 gang accessory box
30mm deep
code
description pack
ESSB2SG
ABS
1
ESSB402WH
polycarbonate 1
*Supplied complete with earth terminal
Bonding strap
code description pack
LBS5
end cap to base 1
Plastic dividing fillet
(un-punched)
code length
pack
LP1006
1.45m
1
Coupler Pin
code description
pack
LDP1
ø2.0 x 20mm
10
Dividing fillet
(pre-punched)
code length
pack
LP1005
1.45m
1
To aid alignment of base profiles
Earth bonding kit
code
pack
LBT3
1
Note:
Fastons supplied suit
1.5mm to 2.5mm cable (blue)
and 4.0mm to 6.0mm (yellow).
Bonding strap
code description pack
ESBS1
base to base
5
1 gang accessory
plate
code
pack
ESSP1SG
1
2 gang accessory
plate
code
pack
ESSP2SG
1
2 gang adjustable
depth box
code
depth
pack
EAB2SG
32 – 40mm 1
EAB1 and EAB2 are fully adjustable to 47mm.
Please see page 311 for more information.
RCD/MCB Housing
code
pack
EAHC1MWH
1
*Up to 4 modules can
be accommodated
Note:
RCDs and MCBs are not
supplied by Marshall-Tufflex
