58
No. of compartments
Floor box base
Service outlet lush loor trunking
Shallow lush loor trunking 150 x 25 mm – 2 compartment
Shallow lush loor trunking 150 x 38 mm – 2 compartment
Shallow lush loor trunking 150 x 25 mm – 3 compartment
Shallow lush loor trunking 150 x 38 mm – 3 compartment
System type
Shallow lush loor trunking 225 x 25 mm – 3 compartment
Shallow lush loor trunking 225 x 38 mm – 3 compartment
Screed loor box to suit shallow 25 mm ducting
Screed loor box to suit deep 38 mm ducting
Screed loor box to suit 20 mm conduit
Screed loor box to suit 25 mm conduit
Socket plates
13 A twin switched socket plate
13 A twin unswitched socket plate
13 A standard
13 A twin switched clean earth socket plate
13 A triple unswitched socket plate
13 A triple unswitched clean earth socket plate
13 A non-standard
13 A twin NS switched socket plate
13 A twin NS switched clean earth socket plate
RCD 30 mA passive
2 gang RCD socket plate
1
2 gang RCD socket plate - clean earth
1
37 x 22 mm – 2 cut-out plate
37 x 22 mm – 4 cut-out plate
Data
37 x 22 mm – 4 cut-out wave plate
1
37 x 22 mm – 6 cut-out plate
47·5 x 23·5 mm – 4 cut-out plate
2 x standard single outlet 60·3 mm
Standard 2 gang outlet plate 120·6 mm
51 x 51 mm – 1 cut-out plate
General
51 x 51 mm – 2 cut-out plate
Blank plate
58 x 53·5 mm – 1 cut-out plate to accept Arteor mounting frame
2
58 x 53·5 mm – 2 cut-out plate to accept 2 x Arteor mounting frames
2
Lids and trims
ABS with carpet trim – 6 mm recess
Combination with edge trim – 6 mm recess
Metal, powder coated with carpet trim – 8 mm recess
Metal, powder coated with edge trim – 8 mm recess
Stainless steel with carpet trim – 8 mm recess
Stainless steel with edge trim – 8 mm recess
Brass with carpet trim – 8 mm recess
Brass with edge trim – 8 mm recess
1 : Due to overall depth, these items will NOT it in the lush loor and shallow lush loor ranges (Cat. Nos. FFO and AFS). When using with underloor duct systems
(Cat. No. AFU) the outlet box must be raised by 8 mm from the lowest point to allow for wiring
2 : For Arteor mounting frames, refer to the latest Wiring Devices catalogue
screed floor service outlet boxes
selection chart
