Shallow flush floor trunking
(continued)
End cap
1
AFS2615
150 x 25 mm
1
AFS2655
150 x 38 mm
1
AFS3915
225 x 25 mm
1
AFS3955
225 x 38 mm
Junction box
Supplied with connections and plates
Can be configured as a fourway, tee,
bend or straight through connector box
2
comp
3
comp
1
AFS2614 AFS3614 150 x 25 mm
1
AFS2654 AFS3654 150 x 38 mm
1
AFS3914 225 x 25 mm
1
AFS3954 225 x 38 mm
Service outlet base boxes
Service outlet base boxes are supplied
empty
Service outlet boxes are 65 mm deep
Due to shallow depth of trunking, box
locations need to be defined and
recessed locally before installation
To complete the system, the outlet base
box requires outlet plates, lid and trim
Outlet plates, lids and trims ordered
separately, (see p. 64)
2
comp
3
comp
1
AFS2BB261AFS3BB361 To suit 150 x 25 mm trunking
1
AFS2BB265AFS3BB365 To suit 150 x 38 mm trunking
1
AFS3BB391 To suit 225 x 25 mm trunking
1
AFS3BB395 To suit 225 x 38 mm trunking
4
comp
1
AFS4BB261
To suit 150 x 25 mm trunking
1
AFS4BB265
To suit 150 x 38 mm trunking
1
AFS4BB361
To suit 150 x 25 mm trunking
1
AFS4BB365
To suit 150 x 38 mm trunking
1
AFS4BB391
To suit 225 x 25 mm trunking
1
AFS4BB395
To suit 225 x 38 mm trunking
Pack
Cat. Nos.
Shallow flush floor trunking
Trunking length – 2 m
2
comp
3
comp
1
AFS261 AFS361 150 x 25 mm
1
AFS265 AFS365 150 x 38 mm
1
AFS391 225 x 25 mm
1
AFS395 225 x 38 mm
Spare connector set
1
AFS3611
150 mm wide
1
AFS3911
225 mm wide
90° riser bend
Supplied with screeding cover
Provides conduit entry with
20 mm knockouts
2
comp
3
comp
1
AFS2613 AFS3613 150 x 25 mm
1
AFS2653 AFS3653 150 x 38 mm
1
AFS3913 225 x 25 mm
1
AFS3953 225 x 38 mm
Back entry skirting adaptor
1
AFSS
F
SK
S
To complete the Cat. No. specify :
F
= shallow flush floor
trunking size code
S
= skirting trunking height
in inches
Example : AFSS 361 SK6
Cable trunking adaptor
Supplied with turnbuckle fix lid
1
AFST
FT
To complete the Cat. No. specify :
F
= shallow flush floor trunking size code
T
= standard cable trunking
Cat. No.
Example : AFST 361 MGR623C
Trunking length
AFS361
Body and lid manufactured from pre-galvanised sheet steel to BS EN 10142 and 3
Standard lengths : trunking 2
.
0 m, lid 0
.
5 m
Standard lid thickness : 2
.
5 mm
Each 2 m length is fitted with 4 x 500 mm long lids and supplied complete with all necessary connectors and screws
commercial floor trunking systems
shallow flush floor trunking
Shallow flush floor trunking
can be supplied in different
widths and depths
Contact us on +44 (0) 870 608 9020
Screed loor outlet boxes selection chart
p. 58-59
Dimensions and technical information
p. 67
Installation details
p. 69
