51
Pack
Cat. Nos.
Universal outlets
Accessory outlet tile
1
8400040 225 x 225 mm
Used to fix power poles,
cable snake or grommets
Aluminium power pole
1
8650210 670 mm high
1
821830 Single power pole back box
1
8400050 Accessory outlet tile fixing bracket
Accessories
1
8190232 Chrome outlet grommet
1
8190640 Grey cable snake
1
8190641 Black cable snake
1
8400030 Cable outlet tile
Cable management floor system
225 x 225 mm tiles manufactured from pre-galavanised steel with
13 mm return
Integrated earthing design
Click fit, no fixings required
Supports manufactured from recycled polypropylene
Pack
Cat. Nos.
Floor box for 60, 90 and 120 mm high
systems only
Floor box
1
8409081 450 x 450 mm floor box tile
1
821821 Floor box lid and trim
Outlet plate options
1
821822 3 compartment twin switched
socket module
1
821824 3 compartment blank module
1
821826 3 compartment data module
(4 x 37 x 22 mm cut-outs)
1
821823 4 compartment twin switched
socket module
1
821825 4 compartment blank module
1
821827 4 compartment data module
(4 x 37 x 22 mm cut-outs)
Outlet solutions for 37 mm high systems
Semi-submerged
1
8403750 37 mm power outlet to accept
2 x Arteor double modules
1
1
8403751 37 mm data outlet to accept
2 x Arteor double modules
1
Outlet solutions for 60 mm high systems
Fully submerged
1
8406072 60 mm power outlet to accept
2 x Arteor double modules
1
1
8406073 60 mm data outlet to accept
2 x Arteor double modules
1
Floor box tile
8409081
Ramp
8406040
Support
8406000
Cable outlet tile
8400030
Accessory outlet tile
8400040
Step corner
8406030
Step
8406022
1 :
For Arteor modules, refer to the latest
Wiring Devices catalogue
Soluflex
®
ultra low cavity floor system
(continued)
Selection chart
p. 48-49
Installation instructions
p. 53
Dimensions
p. 54-55
