Fuse Combination Switches & Switch Disconnectors
Dimensions
3.51
Sales Service Centre • 01952 675612 Technical Support Helpline • 01952 675689
Fuse Combination Switches
All dimensions are in mm and exclude the handle.
Add 45mm to the depth to allow for the handle (110mm for 630 /
800A)
SPSN
Dimensions (mm)
Description Width
Height
Depth
JFB202U 20A SPSN 200
250
150
JFB203U 32A SPSN 200
250
150
JFD206U 63A SPSN 300
325
150
JFE210U 100A SPSN 375
400
200
Cable Extension Boxes for Fuse Combination Switches
Dimensions (mm)
Rating
Width
Height
Depth
JZA701 125 / 250A 375
200
200
JZA702 315 / 400A 500
250
300
JZA703 630 / 800A 600
300
350
Switch Disconnectors
All dimensions are in mm and exclude the handle.
3 Pole
Dimensions (mm)
Description Width Height
Depth Handle
Depth
JAC316 160A TPN 250
300
150
195
JAE320 200A TPN 375
400
200
245
JAE325 250A TPN 375
400
200
245
JAG331 315A TPN 375
500
200
245
JAG340 400A TPN 375
500
200
245
JAH363 630A TPN 500
650
300
345
JAH380 800A TPN 500
650
300
345
4 Pole
Dimensions (mm)
Description Width Height
Depth Handle
Depth
JAB402B 20A TPSN 175
232
65
78
JAB403B 32A TPSN 175
232
65
78
JAB406B 63A TPSN 175
232
65
81
JAB410B 100A TPSN 200
300
80
97
JAC412B 125A TPSN 200
300
80
97
JAC416 160A TPSN 250
300
150
195
JAE420 200A TPSN 375
400
200
245
JAE425 250A TPSN 375
400
200
245
JAG431 315A TPSN 375
500
200
245
JAG440 400A TPSN 375
500
200
245
JAH463 630A TPSN 500
650
300
345
JAH480 800A TPSN 500
650
300
345
TPN
Dimensions (mm)
Description Width
Height
Depth
JFB302U 20A TPN
200
250
150
JFB303U 32A TPN
200
250
150
JFD306U 63A TPN
300
325
150
JFE310U 100A TPN 375
400
200
JFG312U 125A TPN 375
500
200
JFG316U 160A TPN 375
500
200
JFG320U 200A TPN 375
500
200
JFG325U 250A TPN 375
500
200
JFH331U 315A TPN 500
650
300
JFH340U 400A TPN 500
650
300
JFI363U 630A TPN 600
800
350
JFI380U 800A TPN 600
800
350
TPSN
Dimensions (mm)
Description Width
Height
Depth
JFB402U 20A TPSN 200
250
150
JFB403U 32A TPSN 200
250
150
JFD406U 63A TPSN 300
325
150
JFE410U 100A TPSN 375
400
200
JFG412U 125A TPSN 375
500
200
JFG416U 160A TPSN 375
500
200
JFG420U 200A TPSN 375
500
200
JFG425U 250A TPSN 375
500
200
JFH431U 315A TPSN 500
650
300
JFH440U 400A TPSN 500
650
300
JFI463U 630A TPSN 600
800
350
JFI480U 800A TPSN 600
800
350
