Invicta 3 Panelboard System (400A, 630A & 800A Rated)
Dimensions
3.48
General Catalogue • Commercial Distribution • Technical
Primary Boards
Dimensions (mm)
Height
Width
Depth
JF406B/G 1250
900
220
JF408B/G 1250
900
220
JF412B/G 1400
900
220
JF416B/G 1550
900
220
JF418B/G 1700
900
220
JF808B/G 1250
900
220
JF812B/G 1400
900
220
JF818B/G 1700
900
220
JF60204B/G 1250
900
220
JF80206B/G 1250
900
220
JF80404B/G 1250
900
220
JF80210B/G 1400
900
220
JF80408B/G 1400
900
220
JF80414B/G 1700
900
220
JF80612B/G 1700
900
220
Terminals
Neutral
Earth
Bond
2 x 9 x 50mm
2 x 9 x 50mm 1 x 3 x 50
2 x 12 x 50mm
2 x 12 x 50mm 1 x 3 x 50
2 x 18 x 50mm
2 x 18 x 50mm 1 x 3 x 50
2 x 24 x 50mm
2 x 24 x 50mm 1 x 3 x 50
2 x 12 x 50mm
2 x 12 x 50mm 1 x 3 x 50
2 x 18 x 50mm
2 x 18 x 50mm 1 x 3 x 50
2 x 27 x 50mm
2 x 27 x 50mm 1 x 3 x 50
2 x 6 x 50mm 2 x M8 Bolt
2 x 9 x 50mm 1 x 3 x 50
2 x 9 x 50mm 2 x M8 Bolt
2 x 12 x 50mm 1 x 3 x 50
2 x 6 x 50mm 4 x M8 Bolt
2 x 12 x 50mm 1 x 3 x 50
2 x 15 x 50mm 2 x M8 Bolt
2 x 18 x 50mm 1 x 3 x 50
2 x 12 x 50mm 4 x M8 Bolt
2 x 18 x 50mm 1 x 3 x 50
2 x 21 x 50mm 4 x M8 Bolt
2 x 27 x 50mm 1 x 3 x 50
2 x 18 x 50mm 6 x M8 Bolt
2 x 27 x 50mm 1 x 3 x 50
Cables outgoing ways:
25 - 50mm
2
CSA Flex
25 - 70mm
2
CSA Solid
MCCB Connections
400A M10
630A M12
Earth
400A M10
630A M10
Extension Boxes
Dimensions (mm)
Height
Width
Depth
JF801E/G 300
900
220
JF803E/G 450
900
220
JF805E
300
900
158
JF806E
450
900
158
L1 L2 L3
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
B1
B2
B3
10
11
12
13
14
15
16
17
18
ISOLATEBEFORE
REMOVINGCOVER
ISOLATEBEFORE
REMOVINGCOVER
L1
L2
L3
L1
L2
L3
L1
L2
L3
Height
Depth
Width
Width
Height
Depth
