General Catalogue • Commercial Distribution
invicta 3 Panelboard System (400A Rated)
400A Incoming 125A Outgoing
invicta 3 Panelboards (400A Incoming 125A Outgoing)
Comprises of enclosure, pan assembly, neutral bar and earth bar.
Supplied without incoming kit (one of the incomer kits listed below must be used).
Description
Cat ref.
Cat ref.
Plain door
Glazed door
6 Way
JF406B
JF406BG
8 Way
JF408B
JF408BG
12 Way
JF412B
JF412BG
16 Way
JF416B
JF416BG
18 Way
JF418B
JF418BG
Incomer Kits
Description
Cat ref.
3 Pole 400A MCCB Incomer Kit 50kA
JF443BM
(Adjustable Thermal 0.4, 0.5, 0.63, 0.8, 0.9, 0.95 1.0 x I n ) (Electronic LSI x7 I r Characteristics)
4 Pole 400A MCCB Incomer Kit 50kA
JF444BM
(Adjustable Thermal 0.4, 0.5, 0.63, 0.8, 0.9, 0.95 1.0 x I n ) (Electronic LSI x7 I r Characteristics)
3 Pole 400A Switch Disconnector (Non-Auto MCCB) Incomer Kit
JF443BS
4 Pole 400A Switch Disconnector (Non-Auto MCCB) Incomer Kit
JF444BS
400A Direct Connection Kit
JF444BD
For RCD incomer option contact our technical support helpline on 01952 675689
Options
Key lock, meter pack, DIN rail,
extension box, spreader box.
Construction
Enclosures manufactured from
1.5mm DC01M cold reduced
mild steel, phosphate pretreated
and powder coated to 00A01
BS4800.
Specification
Complies with BS EN 61439-2.
Enclosure degree of protection:
IP3X
Internal separation
Form 3A
6, 8, 12, 16, 18 Triple Pole
outgoing ways.
Cable Capacity Incomers
3 and 4 pole MCCB.
Cable capacity 240mm
2
max lug width 35mm.
3 and 4 pole non auto MCCB.
Cable capacity 240mm
2
.
Max lug width 35mm on
extended connections fitted to
incomer.
Direct connection kit.
M10 hexagonal bolt
Cable Capacity Outgoers
1 & 3 pole MCCB 70mm
2 flexible.
1 & 3 pole MCCB 95mm
2
solid.
Busbar Ratings
Busbar rated current:
400A continuous
Busbar rated short-time
withstand current 35kA for 1s
direct connected (unconditional)
Outgoing MCCBs
Single pole 16-125A
(10 ratings).
Fixed thermal, fixed magnetic
trips.
Triple pole 20-125A (6 ratings)
adjustable thermal fixed
magnetic trips.
For dimensions see page 3.40.
400A Rated Pan Assemblies
Description
Cat ref.
JF406B 6 Way Pan Assembly
JF406BPA
JF408B 8 Way Pan Assembly
JF408BPA
JF412B 12 Way Pan Assembly
JF412BPA
JF416B 16 Way Pan Assembly
JF416BPA
JF418B 18 Way Pan Assembly
JF418BPA
Outgoing Devices
MCCBs - Single Pole
Rating.
18kA Fixed Thermal
25kA Fixed Thermal
Mag 10 x I n
Mag 10 x I n
16A
HDA014Z
HHA014Z
20A
HDA018Z
HHA018Z
25A
HDA023Z
HHA023Z
32A
HDA030Z
HHA030Z
40A
HDA038Z
HHA038Z
50A
HDA048Z
HHA048Z
63A
HDA061Z
HHA061Z
80A
HDA078Z
HHA078Z
100A
HDA098Z
HHA098Z
125A
HDA123Z
HHA123Z
MCCBs - Triple Pole Adjustable Thermal
18kA Adjustable Thermal
25kA Adjustable Thermal
0.63 - 0.8 - 1x I n
0.63 - 0.8 - 1x I n
Rating.
Mag 10 x I n
Mag 10 x I n
25A
HDA025U
HHA025U
40A
HDA040U
HHA040U
63A
HDA063U
HHA063U
80A
HDA080U
HHA080U
100A
HDA100U
HHA100U
125A
HDA125U
HHA125U
JF406B
