3.35
invicta 3 Panelboard system (800A MCCB)
800A Incoming 125 / 250A Outgoing
The Hager range of 800A panel
boards has been designed to
complement our invicta 3
distribution system.
The 800A MCCB incomer board
is designed specifically for
applications where an adjustable
800A MCCB incomer device is
required.
Construction
The enclosure is manufactured
from 1.5mm DC01M cold
reduced mild steel, phosphate
treated and powder coated to
00A01 BS4800.
Busbar Rated current: 800A
35kA for 1 sec.
Removable gland plates are
provided top and bottom for
ease of installation”
Specification
Complies with BS EN 61439-2
Enclosures degree of protection:
IP3X
Internal Separation: Form 3A
Cable Capacity:
Outgoing devices
125A frame (16 - 125A)
Flexible: min 6mm², max 70mm²
Rigid: min 6mm², max 95mm²
250A frame (100 - 250A)
Lug connection: max width
25mm, M8.
For dimensions see page 3.41
invicta 3 Panelboards (800A Incoming 125A Outgoing)
Max. 125A outgoing devices
Description
Cat ref.
Cat ref.
Plain door
Glazed door
12 Way
JHF812B
JHF812BG
18 Way
JHF818B
JHF818BG
invicta 3 Panelboards (800A Incoming 125A / 250A Outgoing)
These boards will accept two MCCB frame sizes
125A frame: 16 - 125A
250A frame: 100 - 250A
Description
Cat ref.
Cat ref.
Plain door
Glazed door
8 Way (2 x 250A
+ 6 x 125A
)
JHF80206B JHF80206BG
8 Way (4 x 250A
+4 x 125A
)
JHF80404B JHF80404BG
12 Way (2 x 250A
+ 10 x 125A
)
JHF80210B JHF80210BG
12 Way (4 x 250A
+ 8 x 125A
)
JHF80408B JHF80408BG
18 Way (4 x 250A
+ 14 x 125A
)
JHF80414B JHF80414BG
18 Way (6 x 250A
+ 12 x 125A
)
JHF80612B JHF80612BG
Incomer Kits
Description
Cat ref.
Plain door
800A 3 Pole MCCB Incomer Auto 50kA
JHF883BM
800A 4 Pole MCCB Incomer Auto 50kA
JHF884BM
MCCBs - 125A 18kA Single Pole
Rating.
18kA Fixed Thermal
25kA Fixed Thermal
16A
HDA014Z
HHA014Z
20A
HDA018Z
HHA018Z
25A
HDA023Z
HHA023Z
32A
HDA030Z
HHA030Z
40A
HDA038Z
HHA038Z
50A
HDA048Z
HHA048Z
63A
HDA061Z
HHA061Z
80A
HDA078Z
HHA078Z
100A
HDA098Z
HHA098Z
125A
HDA123Z
HHA123Z
MCCBs - 125A 25kA Triple Pole Adjustable Thermal
18kA Adjustable Thermal
25kA Adjustable Thermal
Rating.
0.63 - 0.8 - 1x I
n
0.63 - 0.8 - 1x I
n
Mag 10 x I n
Mag 10 x I n
25A
HDA025U
HHA025U
40A
HDA040U
HHA040U
63A
HDA063U
HHA063U
80A
HDA080U
HHA080U
100A
HDA100U
HHA100U
125A
HDA125U
HHA125U
Outgoing Devices
MCCBs x250 40kA - Triple Pole
Rating.
Cat ref.
100A
HNB100H
125A
HNB125H
160A
HNB160H
200A
HNB200H
250A
HNB250H
