General Catalogue • Commercial Distribution • Technical
invicta 3 Panelboard System
Characteristics
250A
400A
630 / 800A
800A
Series
JN2**
JF4**
JF6**/JF8**
JHF8**
Busbar current rating
250A
400A
800A
800A (for 800A MCCB only)
Busbar type
Type B Fully Shrouded Copper
Busbar rated short-time
withstand current
25kA for 1 sec
35kA for 1 sec
35kA for 1 sec
35kA for 1 sec
Internal separation
Form 3A
Incoming
Up to 250A MCCB, MCS Up to 400A MCCB, MCS Up to 630A MCCB, 800A
LBS
800A MCCB
Outgoing
16 - 125A max.
16 - 125A max.
16 - 125A
100A - 250A
16 - 125A
100A - 250A
Voltage rating in AC
415V
415V
415V
415V
IP Protection
IP3X
Enclosure body type
Steel
Enclosure paint type
Powder coat Grey white RAL 9002
Cable entry
Via Gland Plates
Terminal Connection capacity
Incoming earth terminal
M8
M10
M10
M10
Incoming neutral terminal
M8
M12
M12
M12
Outgoing earth terminals Up to 50mm²
Up to 50mm²
Up to 50mm²
Up to 50mm²
Outgoing neutral terminals Up to 50mm²
Up to 50mm²
16A - 125A: Up to 50mm
2
100A - 250A: M8 Stud
16A - 125A: Up to 50mm
2
100A - 250A: M8 Stud
Enclosure earth stud
M8
M10
M10
M10
Max. Terminal capacity 185mm
2
(cage)
240mm
2
(cage)
-
-
Installation
Mounting
Surface (Wall)
