invicta 3 Panelboard System (630A / 800A Rated)
630 / 800A Rated Pan Assemblies
630A / 800A Rated Pan Assemblies
Description
Cat ref.
JF608B Pan Assembly
JF608BPA *
JF812B Pan Assembly
JF812BPA
JF818B Pan Assembly
JF818BPA
JF80210B Pan Assembly
JF80210BPA
JF60204B Pan Assembly
JF60204BPA *
JF80206B Pan Assembly
JF80206BPA
JF80408B Pan Assembly
JF80408BPA
JF80414B Pan Assembly
JF80414BPA
JF80404B Pan Assembly
JF80404BPA
JF80612B Pan Assembly
JF80612BPA
* These pan assemblies are rated at 630A
MCCBs - 125A 18kA Single Pole
Rating.
18kA Fixed Thermal
25kA Fixed Thermal
16A
HDA014Z
HHA014Z
20A
HDA018Z
HHA018Z
25A
HDA023Z
HHA023Z
32A
HDA030Z
HHA030Z
40A
HDA038Z
HHA038Z
50A
HDA048Z
HHA048Z
63A
HDA061Z
HHA061Z
80A
HDA078Z
HHA078Z
100A
HDA098Z
HHA098Z
125A
HDA123Z
HHA123Z
MCCBs - 125A 25kA Triple Pole Adjustable Thermal
18kA Adjustable Thermal
25kA Adjustable Thermal
Rating.
0.63 - 0.8 - 1x I
n
0.63 - 0.8 - 1x I
n
Mag 10 x I n
Mag 10 x I n
25A
HDA025U
HHA025U
40A
HDA040U
HHA040U
63A
HDA063U
HHA063U
80A
HDA080U
HHA080U
100A
HDA100U
HHA100U
125A
HDA125U
HHA125U
Outgoing Devices Thermal Magnetic
MCCBs x250 40kA - Triple Pole
Adjustable Thermal &
Magnetic
Rating.
Cat ref.
100A
HNB100H
125A
HNB125H
160A
HNB160H
200A
HNB200H
250A
HNB250H
