Dimensions (mm)
1
2
1
90
90
40
40
1
2
1
90
90
40
40
CT1
CT2
Component Selection Guide (dimensions in mm)
EGA CORNICE CABLE CAPACITY
TYPE OF
CONDUCTOR SIZE
CABLE
FACTOR
CT1
CT2 CMPT 1
CT2 CMPT 2
Full Term CSA 100% Fill (mm
²
)
755
636
1441
Term at 45% Fill (mm
²
)
339
286
648
Power Cables
Number of Cables at 45% Fill
PVC Stranded 1.5mm²
8.6
39
33
75
2.5mm²
12.6
26
22
51
4mm²
16.6
20
17
39
6mm²
21.2
15
13
30
Data Cables
No. of Cables at 45% Fill (a) and Full Capacity (b)
a
b
a
b
a
b
Cat5E UTP 5.5mm dia.
30.2
11
25
9
21
21
47
Cat5E STP 6.0mm dia.
36.0
9
20
7
17
18
40
Cat6 UTP 6.5mm dia.
42.2
8
17
6
15
15
34
Cat6 STP 7.0mm dia.
49.0
6
15
5
12
13
29
PROFILE
JOINT COVER
40 x 40mm (CT1)
CJC1
90 x 90mm (CT2)
CJC2
PROFILE
MINI TRUNKING ADAPTOR
40 x 40mm (CT1)
CA1
90 x 90mm (CT2)
CA2
PROFILE
INT CORNER
40 x 40mm (CT1)
CIP1
90 x 90mm (CT2)
CIP2
PROFILE
EXT CORNER
40 x 40mm (CT1)
CXP1
90 x 90mm (CT2)
CXP2
PROFILE
END CAP
40 x 40mm (CT1)
CEP1
90 x 90mm (CT2)
CEP2
