Industrial Trunking
Components
The following components are fabricated sections and space must be
allowed for inclusion in runs of trunking. All other components fit over
standard trunking profiles.
A
B
H
H
E
E
FLAT TEE (FTF)
FLAT CROSS (FCU)
FLAT ANGLE (FAF)
F
F
G
G
EXTERNAL CORNER (FAE)
INTERNAL CORNER (FAI)
Dimensions
LIST. NO.
COMPONENTS DIMENSIONS (mm)
CLT/
A
B
E
F
G H
CLT1
*100
*90
*80
*125
*65
*100
CLT2
*150
*115
115 110
60
*150
CLT3
*150
*115
*115
150
75
*150
CLT4
220
160
160
110
60
220
CLT5
250
175
175
150
75
250
CLT6
250
175
175
175
75
250
CLT7
330
240
240
165
90
330
CLT8
380
265
265
215
115
380
CLT9
380
265
265
265
115
380
* indicates moulded items
CLT9
Component Selection Guide
