WIRING DEVICES
mkelectric.co.ukTIA WIRING SCHEME COLOUR CODES
PIN NO.
568A
568B
1
WHITE / green
WHITE / orange
2
GREEN / white
ORANGE / white
3
WHITE / orange
WHITE/ green
4
BLUE / white
BLUE / white
5
WHITE / blue
WHITE / blue
6
ORANGE / white
GREEN / white
7
WHITE / brown
WHITE / brown
8
BROWN / white
BROWN / white
P3
P1
P2
P4
568A
P2
P1
P3
P4
568B
Pair 1 – BLUE/white & WHITE/blue
Pair 2 – ORANGE/white & WHITE/orange
Pair 3 – GREEN/white & WHITE/green
Pair 4 – BROWN/white & WHITE/brown
1
2
3
E
F
G
H
50057132
50057133
4
5
6
1
2
3
7
8
1 6
2 5
3 4
1
2
2
8
RJ45 Cat.5e Euro K5845
1
2
3
4
F
G
H
50057132
50057133
50057139
4
5
6
1
2
3
7
8
1 6
2 5
3 4
1
3
6
2
2
4
8
5
RJ45 Cat.5e LJU6C K5745
1
2
3
4
A
B
C
D
E
50057134
1
2
6
3
1 7 4 5
RJ45 Cat.5e Euro - Angled K5844
1
2
3
D
E
F
G
H
1 7 4 5
RJ45 Cat.6 Euro - Angled K5746 - LJU6C
K5846 - Euro, K5864 - Euro Angled
1
2
3
4
A
B
C
D
50057136
8
7
4
53
1
6
2
RJ45 Cat.6 Screened
K5746S - LJU6C, K5846S - Euro
1
2
3
A
B
C
D
8
7
4
53
1
6
2
RJ45 Cat.5e Screened
K5845S - Euro
RJ45 Data Outlets
Description
Suitable for use in all LJU6C and Euro frontplates, available in the Logic Plus range,
Cat 5e and Cat 6 modules suitable for use in structured cabling distribution systems.
Installation details and wiring diagram illustrations
Standards and approvals
ISO/IEC 11801
EN 50173
TIA 568
EN 41003
Installation
l
Maximum cable length 90m.
l
Cable bend radii, 40mm during installation, 20mm
after installation.
l
Maximum pull force 8.7kg.
l
Do not over tighten cable ties.
l
Do not unwind the twists in the wire pairs by more
than 13mm max.
Euro and LJU6C modules are to be wired as follows
Wiring Devices Technical
