WIRING DEVICES
Technical Hotline
+44 (0)1268 563720
OVERLOAD MANAGEMENT
60-500W CIRCUIT
40-300W CIRCUIT
LED INTELLIGENT DIMMER
60-500W nominal
40-300W nominal
40-300W nominal
60-625W function without
dimming
40-375W function without
dimming
40-375W function without
dimming
> 625-750W dim to 68V±8V
r.m.s.
> 375-500W dim to 68V±8V
r.m.s.
> 375-600W dim to
minimum level
> 750W switch off
> 500W switch off
> 600W switch off
LOAD TYPES AND LOADINGS
DIMMER SERIES
DIMMER SIZE
(1 GANG)
RATING
MAX NO. OF TRANSFORMERS AND LEDS
(TOTAL RATING MUST NOT EXCEED
MAX.VARATING OF DIMMER)
GLS AND MAINS
VOLTAGE HALOGEN
ELECTRONIC OR
WIRE WOUND LV
TRANSFORMERS
LED
TRANSFORMERS
LEDS
INTELLIGENT
DIMMER SWITCHES
single dimmer
40-300W
40-240W/VA
–
4
–
double dimmer
2 x 40-300W
2 x 40-240W/VA
–
4 per dimmer
–
single dimmer
60-500W
60-400W/VA
–
5
–
STANDARD DIMMER
SWITCHES
single dimmer
40-250W
–
–
–
–
double dimmer
2 x 40-250W
–
–
–
–
single dimmer
65-450W
–
–
–
–
LED INTELLIGENT
DIMMER SWITCHES
single dimmer
40-300W
40-240W/VA
4-70W
4
10
double dimmer
2 x 40-300W
2 x 40-240W/VA
2 x 4-70W
4 per dimmer
10 per dimmer
N
L
L
1
L
2
C
Two-way switching
(only one dimmer can be used)
L
1
L
2
C
Load
DIMMER
Supply 230V a.c. - 50Hz
2wayswitch
L
N
One-way switching
L
1
L
2
C
Load
DIMMER
Supply 230V a.c. - 50Hz
Wires must be connected to the correct dimmer terminals.
DO NOT connect earth to dimmer.
L
N
Fluorescent dimmer
1
2
HF Fluorescent
Ballast
3
+
–
1-10V
DIMMING
CONTROLLER
Please note the dimmer may be substituted for any
Two-Way switches.
Do not connect more than the maximum number of transformers stated for each dimmer.
Dimmer Switches
FEATURES
Intelligent and LED Intelligent Dimmer Switches
incorporate the following advanced features
l
Suitable for dimming Low Voltage Halogen lamps via good quality,
fully dimmable electronic or wire-wound transformers. In addition,
LED Intelligent dimmer switches are suitable for dimmable LED bulbs
for incandescent replacement.
l
Can be used with good quality mains voltage halogen lamps
incorporating GU10 bases. Please check with lamp manufacturer to
determine suitability
l
Load current sensing:
These dimmers continuously monitor the load current to help protect
against overheating in wire wound transformers and to prevent
overloading of the dimmer for long term reliability
l
Soft Start, which gradually increases the light output from the load
over 1 to 3 seconds after switch on. The Soft Start feature is also
particularly beneficial when used to dim Mains Voltage Tungsten
Halogen lamps which inherently have a very high inrush current at
switch on
Standard Dimmer Switches
l
Suitable only for use with fused GLS Tungsten Filament lamps to
BS EN 60064 and BS EN 60432-1
l
One way dimmer switches incorporate manual soft start
l
Incorporate thermal switches for protection against overload
