20 / 140
20/16
CI insulated enclosures
Enclosure bases
2010
CA08103002Z-EN
www.eaton.comBasic enclosures
EnclosurebasesBasicenclosures
Dimensions
Cable entry
Part no.
Article no.
Price
See price
list
Std. pack
Width
Height
Top and
bottom
Sideways
mm
mm
Bases for E-type individual enclosures
•
Metric cable entry knockouts in all sides
•
Full-area knockouts in the sides
187.5
250
1
x M32/20
6
x M20
2
x M16
2
x M32/20
4
x M25/16
4
x M20
4
x M16
U-CI23E
038793
1
off
375
250
2
x M50/32
6
x M25/16
8
x M20
1
x M50/32
6
x M25/16
U-CI43E
064896
375
1
x M50/32
2
x M40/25
8
x M25/16
2
x M20
1
x M63/40
6
x M25/16
10
x M20
2
x M16
U-CI44E
069642
500
1
x M50/32
2
x M40/25
8
x M25/16
2
x M20
On each 2:
1
x M50/32
6
x M25/16
U-CI45E
001893
Bases for X type individual enclosures
•
Smooth side plates, without knockouts
187.5
250
Drill as
required
Drill as
required
U-CI23X
057909
1
off
375
250
U-CI43X
062655
375
U-CI44X
067401
500
U-CI45X
098470
Bases for panel enclosures
•
Sides closed, but with full area knockout
•
Open tip and bottom
187.5
250
Via FL2...
flange
Via FL3...
flange
U-CI23
060282
1
off
375
250
Via FL4...
flange
Via FL3...
flange
U-CI43
065028
375
Via FL4...
flange
Via FL4...
flange
U-CI44
067269
500
Via FL4...
flange
Via FL3...
flange
U-CI45
001894
750
Via FL4...
flange
Via FL4...
flange
U-CI48
083880
Notes
Flange￫Page 20/23
Enclosure intermediate frame
•
For increased mounting depth
•
Smooth side plates, without knockouts
•
Color RAL 7032, pebble grey
•
Screw-fitting cover fastener
•
Equipment supplied: gasket, mounting accessories
Dimensions
Mounting
depth
1)
For use with
Part no.
Article no.
Price
See price
list
Std. pack
Width
Height
mm
mm
mm
375
500
275
U-CI45...
D200-CI45
CI45...
U-CI45-DR
110103
1
off
Notes
1)
with cover D200-CI45
U-CI...
HPL20016EN
