CS sheet steel wall-mounting enclosure
General
2010
CA08103002Z-EN
www.eaton.comGeneral
Technical data
CS-...
General
Standards
IEC/EN 60529, IEC 62262, IEC/EN 62208
RoHS
In accordance with Directive 2002/95/EC of the European Parliament and Council
Climatic proofing
Damp heat constant to IEC 60068-2-78; Damp heat, cyclical to IEC 60068-2-30
Ambient temperature
°C
-40 -
+70
Protection type
IP66
Protection type with ventilating louvers
IP23
Installation site conditions
Installation indoor/outdoor
Mounting grid
mm 25
Heat dissipation
See separate table
Material properties
Material
Sheet steel
Surface treatment
Structured powder spray polyester based paint finish
Colour
RAL 7035, light grey
Surface
Semi-textured
Gloss
Brilliant
Body
mm ≤ CS-65/…: 1.2; ≥ CS-66/…: 1.5
Mounting plate
mm 2; from height 800 × width 400 mm: 3
Door
mm ≤ CS-43/…: 1.0; ≤ CS-64/…: 1.2; ≤ CS-88/…: 1.5; ≤ CS-1212/…: 2.0
Bottom panel
mm 1.5
Material properties
Mechanical
Impact resistance
IK09 according to EN 62262
Total assembly weight of switch cabinet
See separate table
Assembly weight of door
See separate table
Assembly weight of mounting plate
See separate table
Assembly weight of wall fixing bracket
See separate table
Description/standard features
Construction
Canted and seam welded, including two M6 threaded bolts for earth conductor
connections inside the enclosure.
Rear panel
9
mm drilling dimensions for wall mounting
Enclosure side panels
Closed
Top plate flanges
Closed
Bottom panel
Enclosed, foamed gasket, can be unscrewed for F3A flanges -…
or for assembly by user
Mounting panel
Basic features, sheet steel, sendzimir galvanized. Distance from back plate 15 mm.
Mounted on M8 copper threaded welded studs on inside of back plate. An additional
earth conductor connection is therefore not imperative.
Door
Including 1 one threaded welded stud M6 for earth conductor connections in the door.
If electrical apparatus is to be installed in the door, a continuous, permanent
protective contactor connection must be established with a protective ground cable.
The threaded welded studs on the door and on the cabinet side wall must be used as
connecting points for the ground leads.
Hinge position
On the right, can be converted by user
Door opening angle
°
120
Locking system
Twist lock with protective insulation. Standard locking 3 mm two-way key bit.
Locks
Number
See Ordering pages
CS-...
