Eaton Industrial Switchgear - Xboard Optimal switchgear enclosure

125 / 140

CS sheet steel wall-mounting enclosure
General panel construction: Cable glands
2010 CA08103002Z-EN
Accessories 21/17
AccessoriesGeneralpanelconstruction:Cableglands
Features Part no.
Article no.
Price
See price
list
Std. pack
Door earthing set
• Cross-section 6 mm2
• Including installation accessories
– BFZ-DES
101665
1 off
Paint finish
• Brush bottle
• For repairing paint damage
– RAL 7035 BPZ-CPS-7035
286771
1 off
Circuit diagram pockets
• Plastic with self-adhesive rear side
• RAL 7035 light grey
DIN A4 landscape SPT4
002275
10 off
DIN A5 landscape SPT5
002276
DIN A6 landscape SPT6
002277
Cable entry Drilling
diameter
External
diameter of cable
For use with NYM/NYY
cable, 4-core
Part no.
Article no.
Price
See price
list
Std. pack
mm mm mm 2
Metric cable glands to EN 50262
• With lock nut and built-in strain relief
• IP68 up to 5 bar, polyamide, halogen-free
• Flammability classification V2 according to UL94
• Colour RAL 7035
M12 12.5 3 - 7 H03VV-F3 x 0.75 mm2,
NYM 1 x 2.5 mm2
V-M12
215078
20 off
M16 16.5 4.5 - 10 H05VV-F3 x 1.5 mm2,
NYM 1 x 16/3 x 1.5 mm2
V-M16
215077
20 off
M20 20.5 6 - 13 H05VV-F4 x 2.5/3 x 4 mm2,
NYM 5 x 1.5/5 x 2.5 mm 2
V-M20
206910
20 off
M25 25.5 9 - 17 H05VV-F5 x 2.5/5 x 4 mm2,
NYM 5 x 2.5/5 x 6 mm2
V-M25
206911
20 off
M32 32.5 13 - 21 NYM 5 x 10 mm 2 V-M32
206912
10 off
M40 40.5 16 - 28 NYM 5 x 16 mm 2 V-M40
209668
10 off
M50 50.5 21 - 35 NYM 4 x 35/5 x 25 mm2 V-M50
206913
5 off
M63 63.5 34 - 48 NYM 4 x 35 mm 2 V-M63
214835
3 off
Multiple gaskets for V-M... cable glands, metric
M25 – 4 x 5 - 6 H03VV-F2 x 0.75/3 x 0.75 mm2 MFD25
215451
50 off
M32 – 4 x 3.5 - 7 H03VV-F4 x 0.75 mm2 MFD32
215452
25 off
Stoppers for unused apertures in MFD... multiple gaskets
M25 – 6 – MFV25-6
215453
50 off
M32 – 7 – MFV32-7
215454
50 off
BFZ, BPZ, SPT, V-M, MFD HPL21017EN
