21/14 CS sheet steel wall-mounting enclosure
Outdoor installation: Mounting accessories
2010 CA08103002Z-EN
Accessories
AccessoriesOutdoor installation:Mountingaccessories
Dimensions Part no.
Article no.
Price
See price
list
Std. pack
Height Width
mm mm
Ventilating louvers
• For direct fastening to the body of the enclosure
• Protection type IP23
• Material: sheet steel with powder coating RAL 7035
• Delivery with fixing material
Arrangement of the ventilation
slits vertically
157 105 LVP-20V12-CS
112907
1 off
Arrangement of the ventilation
slits horizontally
164 105 LVP-20H12-CS
112908
1 off
Arrangement of the ventilation
slits vertically
180 130 LVP-30V15-CS
112909
1 off
Arrangement of the ventilation
slits horizontally
250 130 LVP-30H15-CS
112910
1 off
Length Dimensions Enclosure Part no.
Article no.
Price
See price
list
Std. pack
Width
mm mm
Mast fastening
• For fixing on round or rectangular masts
• Set consisting of profiled busbar, clamping strap and clamping screw
• Sheet steel, galvanized, stainless steel clamping strap
• For mast diameters from 150 mm to 215 mm
– 300
400
500
600
800
MAST-FIT-CS
140478
1 off
Lift eye kit with profile bracket
• For internal enclosure reinforcement for lifting eye
• Eyebolts with thread M12
• Profile bracket of rigid 3 mm sheet steel
• For protection type IP66
• Each set contains 2 lifting eyes, profiles and gaskets
135 – TOR-SET/135-CS
140479
2 off
LVP-CS, MAST-FIT, TOR-SET HPL21014EN
