CS sheet steel wall-mounting enclosure
Outdoor installation: Bottom panels
2010 CA08103002Z-EN
Accessories 21/11
AccessoriesOutdoor installation:Bottompanels
For enclosure dimensions
Width
Flange apertures For use with Part no.
Article no.
Price
See price
list
Std. pack
Number
mm
Bottom panels with flange cutouts
• Not suitable for enclosure CS-…/150
• For flange F3A-…
• With foamed gasket, maximum protection type IP66 for proper application with F3A-…
• Material: sheet steel with powder coating RAL 7035
• Usable as a top panel by turning the enclosure through 180°
300 1 CS-33/200
CS-43/200
AFP-3-CS
112914
1 off
400 1 CS-34-200
CS-44/200
CS-54/200
CS-54/250
CS-64/200
CS-64/250
CS-84/200
CS-84/250
AFP-4-CS
112915
1 off
500 1 CS-55/250
CS-65/200
CS-65/250
CS-75/200
CS-75/250
AFP-5-CS
112916
1 off
600 2 CS-46/200
CS-46/250
CS-46/300
CS-66/200
CS-66/250
CS-66/300
CS-86/200
CS-86/250
CS-86/300
CS-106/250
CS-106/300
CS-126/250
AFP-6-CS
112917
1 off
800 3 CS-68/300
CS-88/200
CS-88/300
CS-108/250
CS-108/300
CS-128/300
AFP-8-CS
112918
1 off
1000 3 CS-810/300
CS-1010/300
CS-1210/300
AFP-10-CS
112919
1 off
1200 2 x 2 CS-1212/250 AFP-12-CS
112920
1 off
Dimensions Enclosure Part no.
Article no.
Price
See price
list
Std. pack
Width Depth
mm mm
Bottom panels without apertures
• Enclosure protection type IP66
• With continuous foamed gasket
• Gasket protected in deep-drawn area
• With powder coating RAL 7035
182 112 SFP-112X182-CS
138738
1 off
232 112 SFP-112X232-CS
138739
1 off
332 112 SFP-112X332-CS
138740
1 off
262 172 SFP-172X262-CS
138741
1 off
332 172 SFP-172X332-CS
138742
1 off
432 172 SFP-172X432-CS
138743
1 off
532 172 SFP-172X532-CS
138744
1 off
732 172 SFP-172X732-CS
138745
1 off
932 172 SFP-172X932-CS
138746
1 off
AFP-CS, SFP-CS HPL21011EN
