CS sheet steel wall-mounting enclosure
Outdoor installation: Wall mounting, locking systems
2010
CA08103002Z-EN
www.eaton.comAccessories
AccessoriesOutdoor installation:Wallmounting, locking systems
Part no.
Article no.
Price
See price
list
Std. pack
Wall fixing brackets sets
•
For fixing on the wall
•
Vertical or horizontal mounting
•
Bracket material: 3 mm galvanized sheet steel
•
One set contains 4 wall fixing brackets with fixing material and gasket IP66.
WFB-SET-CS
112639
1
off
Universal locks
•
Lock label made from high-grade, impact-resistant pressure-cast zinc
•
Metal lock and inserts
•
Powder coated RAL 7037
•
For indoor and outdoor applications
•
Metal lock nut, notched
•
Compatible with standard latches
•
For standardized door cutouts 22.5 × 20.4 mm
–
3
mm two-way key bit
LC-DBIT3-CS
133102
1
off
–
5
mm two-way key bit
LC-DBIT5-CS
133103
1
off
Common locking mechanism Key with two-way key bit
LC-ZSBIT-CS
133104
1
off
Comfort rotary handle
•
Rotary handle for standardized cylinder locks
•
With built-in “locked” indication
•
As retrofitting or complete kit
•
Handle made from high-grade, impact-resistant pressure-cast zinc
•
Suitable for all universal locks LC-...
•
For standardized door cutouts 22.5 × 20.4 mm
•
Powder coated RAL 7037
•
Order cylinder locks separately
Complete kit
Cylinder lock
PHZ-A-COMP
133105
1
off
Retrofitting kit
Cylinder lock
PHZ-A-ADD-ON
133106
1
off
Cylinder locks for comfort handles
•
For comfort rotary and toggle handles
•
Lock cylinder designed to DIN 18252 and DIN EN 1303
•
Cylinder locks 10/30 with nickel silver pin tumblers
•
Lock bit with eight adjustment positions, five pin pairs
•
Common locking or individual key mechanism
•
One key included per cylinder
keyed alike
–
PHZ-E10/30-GS
138574
1
off
keyed different
–
PHZ-E10/30-VS
138575
1
off
Spare key for cylinder lock
•
For cylinder lock PHZ-E…-GS
keyed alike
Cylinder lock
KEY-E10/30-GS
138576
4
off
WFB-CS, LC-CS, PHZ
