126 / 140
21/18
CS sheet steel wall-mounting enclosure
General panel construction: PG cable glands, ventilation cable glands
2010
CA08103002Z-EN
www.eaton.comAccessories
AccessoriesGeneralpanelconstruction:PGcableglands, ventilationcableglands
Part no.
Article no.
Price
Seeprice
list
Std. pack
Information relevant for export to North America
PG cable glands
•
Conduit union and lock nut with earthing screw
•
Suitable for normal commercial conduit
•
Suitable for all CI...‐NA enclosures
￫Page 20/9
½ "
STB1/2ZOLL
045878
1
off
Product Standards
UL 467; UL 514B; CSA-C22.2
No. 18
UL File No.
E23018, E3060
UL CCN
DWTT, KDER
CSA File No.
LR 2884
CSA Class No.
4412-03, 4414-04
NA Certification
UL Listed, CSA certified
Conditions of Acceptability
Only used in combination
with CI-…-NA enclosures
Specially designed for NA Yes
Suitable for
Conduit, Tubing, and Cable
Fittings, Grounding and
Bonding Equipment
Degree of Protection
Refer to main component
information
See also
Refer to basic component
information
¾ "
STB3/4ZOLL
060116
1 "
STB1ZOLL
052997
1 ¼ "
STB1-1/4ZOLL
043505
1 ½ "
STB1-1/2ZOLL
041132
2 "
STB2ZOLL
002203
Cable entry
Drilling diameter
External diameter
of cable
For use with NYM/NYY cable,
4-
core
Part no.
Article no.
Price
See price
list
Std. pack
mm
mm
mm
2
Ventilation cable gland
•
Colour RAL 7035
Ventilation cable gland IP69K
M20
20.5
6 - 13
H05VV-F 4 x 2.5/3 x 4 mm
2
,
NYM 5 x 1.5/5 x 2.5 mm2
V-M20-VENT
120814
1
off
Ventilation cable gland IP56
•
Permeable to air, impermeable to dust
•
For the prevention of condensation
For use in the enclosure bottom or sides, polyamide, halogen free
M20
20.5
–
–
STB-M20F
224557
20
off
M25
25.5
–
–
STB-M25F
224558
20
off
Pressure compensating plug
Pressure compensating plug, IP66, metric
Colour RAL 7035
M40 x 1.5
–
–
–
DAV-M40
107225
2
off
Pressure compensating plug, IP66, PG
Colour RAL 7032
PG29
–
–
–
DA412
079219
2
off
STB-ZOLL, V-M20-VENT, STB
HPL21018EN
