20/8 CI insulated enclosures
Individual enclosures
2010 CA08103002Z-EN
Basic enclosures
Dimensions Enclosure depth:
Dimensions from top:
1. Mounting depth for mounting plate
2. Mounting depth for mounting rail 7.5 mm height
3. Enclosure depth for mounting rail 15 mm height
4. Enclosure depth
Type cover /
Type
Enclosure base
Part no.
Article no.
Price
See price
list
Std.
pack
mm mm
Individual enclosures E and X
• Protection type IP65
• Cover transparent or non-transparent (RAL 7032, pebble grey)
• Fixing straps for wall fixing
• Sealable cover fasteners
E individual enclosures
• With metric knockouts in all enclosure side plates; see illustrations A to F
• Full-area knockouts in the sides
• Can be converted to distribution board enclosure
X individual enclosures
• Smooth side plates, without knockouts
Transparent
/knockout
CI44E-250
038555
1 off
Transparent
/plain
CI44X-250
038884
Transparent
/knockout
CI45E-200
001891
Non-transparent
/knockout
CI45E-200-RAL7032
090160
Transparent
/plain
CI45X-200
098469
Notes
A B C D
1 x M32/20
6 x M20
2 x M16
2 x M32/20
4 x M25/16
4 x M20
4 x M16
2 x M50/20
6 x M25/16
8 x M20
1 x M50/32
6 x M25/16
E F
1 x M50/32
2 x M40/25
8 x M25/16
2 x M20
1 x M63/40
6 x M25/16
10 x M20
2 x M16
E
F F
375
E
375
275
242.5
250
235
D
E
D
250
500
D
E
D
375
192.5
200
225
185
CI...E, CI...X HPL20008EN
