Eaton Industrial Switchgear - Xboard Optimal switchgear enclosure

11 / 140

CI insulated enclosures
Individual enclosures
2010 CA08103002Z-EN
Basic enclosures 20/7
Dimensions Enclosure depth:
Dimensions from top:
1. Mounting depth for mounting plate
2. Mounting depth for mounting rail 7.5 mm height
3. Enclosure depth for mounting rail 15 mm height
4. Enclosure depth
Type cover /
Type
Enclosure base
Part no.
Article no.
Price
See price
list
Std.
pack
mm mm
Transparent
/knockout
CI44E-125
031436
1off
Non-transparent
/knockout
CI44E-125-RAL7032
090157
Transparent
/plain
CI44X-125
031765
Transparent
/knockout
CI44E-150
033809
Non-transparent
/knockout
CI44E-150-RAL7032
090158
Transparent
/plain
CI44X-150
034138
Transparent
/knockout
CI44E-200
036182
transparent
with transparent
door
/knockout
CI44E-200-T
090147
Non-transparent
/knockout
CI44E-200-RAL7032
090159
Transparent
/plain
CI44X-200
036511
Notes
A B C D
1 x M32/20
6 x M20
2 x M16
2 x M32/20
4 x M25/16
4 x M20
4 x M16
2 x M50/20
6 x M25/16
8 x M20
1 x M50/32
6 x M25/16
E F
1 x M50/32
2 x M40/25
8 x M25/16
2 x M20
1 x M63/40
6 x M25/16
10 x M20
2 x M16
E
F F
375
E
375
150
117.5
125
110
142.5
175
135
150
225
192.5
200
185
CI...E, CI...X HPL20007EN
