Digital devices Z-MG/VD-600 Z-MG/AD-20 Z-MG/AD-999 Z-MG/VD+AD Z-MG/VD+AD+S
Electrical
Rated voltage Un V AC 600 – – 500 500
Rated current In A – 20 5 5 5
Auxilliary voltage 230 V, 50 Hz 230 V, 50 Hz 230 V, 50 Hz 230 V, 50 Hz 230 V, 50 Hz
Intrinsic consumption, auxiliary voltage input VA < 4.5 < 4.5 < 4.5 ≤ 2.5 ≤ 2.5
Input signal Symmetrical, sinusoidal, harmonic factor 1.11
Rated frequency Hz 50 50 50 50 50
Operating frequency Hz 45 - 65 45 - 65 45 - 65 47 - 63 47 - 63
Measuring accuracy ± 1 % + 1 digit ± 1 % + 1 digit ± 1 % + 1 digit ± 1 % + 1 digit ± 1 % + 1 digit
Resolution 1 digit 1 digit 1 digit 1 V/0.01 - 10 A 1 V/0.01 - 10 A
Number of measurements per second 3 3 3 0.67 0.67
Measuring range 0 - Un 0 - In 0 - In 0 - 500 V/01 - 6 A 0 - 500 V/01 - 6 A
Intrinsic consumption
Voltage input VA – – – ≤ 0.1 ≤ 0.1
Current input VA – < 1.1 < 1.1 ≤ 0.6 ≤ 0.6
Input impedance > 1 MΩ – – – –
Measuring range overshoot
Continuous 1.1 x Un 2 x In 2 x In 1.2 x Un/1.2 x In 1.2 x Un/1.2 x In
Momentary – 2.5 x In/5 s 10 x In/5 s 2 x In/5 s 2 x In/5 s
Insulation voltage kV 0.66 0.66 0.66 0.66 0.66
Test voltage 50 Hz/1 min. kV 2 2 2 3 3
Alarm contacts – – – – 2, programmable
Type – – – – Min. and/or max.
Setpoint – – – – 0 - 120 %
Hysteresis – – – – 0 - setpoint value
Delay – – – – 0 - 60 s (1 s steps)
Relay position – – – – Active/passive
Contact rating – – – – 5 A/250 V AC
Mechanical
Standard front dimension mm 45 45 45 45 45
Size of device base mm 89.5 89.5 89.5 89.5 89.5
Built-in width mm 71.2 71.2 71.2 71.2 71.2
Maximum display 999 999 999 999 999
Digit height mm 14 14 14 14 14
Weight kg 0.3 0.3 0.3 0.25 0.27
Mounting Quick attachment for top-hat rail IEC/EN 60715
Degree of protection when fitted IP50 IP50 IP50 IP50 IP50
Terminals top and bottom Lift terminals Lift terminals Lift terminals Lift terminals Lift terminals
Terminal capacity mm2 4 4 4 4 4
Tightening torque of terminal screws Nm 0.6 0.6 0.6 0.6 0.6
Admissible relative humidity % 95 95 95 20 - 80 20 - 80
Temperature range °C -10 - +55 -10 - +55 -10 - +55 -5 - +55 -5 - +55
Flammability classification according to UL94 V1 V1 V1 V1 V1
Z-MG/VD+AD
Z-MG/VD+AD+S
Measuring range,
resolution
Range – – – – – – – – 5 A – – – –
Indication – – – – – – – – 5.00 – – – –
Resolution 10 mA
Range 10 A – 15 A – 20 A 25 A 30 A 40 A 50 A 60 A 70 A 75 A 80 A
Indication 10.0 – 15.0 – 20.0 25.0 30.0 40.0 50.0 60.0 70.0 75.0 80.0
Resolution 100 mA
Range 100 A 120 A 150 A 160 A 200 A 250 A 300 A 400 A 500 A 600 A 700 A 750 A 800 A
Indication 100 120 150 160 200 250 300 400 500 600 700 750 800
Resolution 1 A
Range 1 kA 1.2 kA 1.5 kA 1.6 kA 2 kA 2.5 kA 3 kA 4 kA 5 kA 6 kA 7 kA 7.5 kA 8 kA
Indication 1.00 1.20 1.50 1.60 2.00 2.50 3.00 4.00 5.00 6.00 7.00 7.50 8.00
Resolution 10 A
