Accessories for control panel building
Cable glands, meters for DIN rail
2010 CA08103002Z-EN
16/85
Cableglands,meters forDIN railTechnical data
KT-M… V-M… MFD… MFV… KT-M25F STB-M…F
Material Polyethylene and
thermoplastic
elastomer
Polyamide,
halogen-free
Thermoplastic
elastomer
Polyamide PVC and
polyethylene
Glass-fiber
reinforcedpolyamide
with flame retardant,
self-extinguishing
Color Gray, RAL 7035 Gray, RAL 7035 Black, similar to
RAL 9005
Red Grey, RAL 7032 +
white
Gray, RAL 7035
Degree of protection Up to IP66 IP68 up to 5 bar
(30 min)
IP66 – Up to IP50 IP56, mounting
only on enclosure
underside
Chemical resistance Resistant to:
alcohol, animal and
plant fats, weak
alkalis, light acids,
water
Resistant to:
acetone, petrol,
paraffin, diesel oil,
greases, oils, paint
solvents
– – Resistant to:
diluted non-oxidiz-
ing acids, alkalis
and salt, alcohol,
aromatic and
halogenated
hydrocarbons,
surfactants.
Resistant to:
acetone,
petrol/gasoline,
paraffin, diesel oil,
greases, oils, paint
solvents
Danger of stress fracture Relatively high Low – – Relatively high Low
Temperature resistance -40 °C - 80 °C, up to
about 100 °C for
short periods
-20 °C - 100 °C, up to
about 120 °C for
short periods
-25 °C - 100 °C, up to
about 120 °C for
short periods
-25 °C - 80 °C, up to
about 120 °C for
short periods
0 °C - 60 °C, up to
about 80 °C for
short periods
-40 °C - 100 °C, up to
about 150 °C for
short periods
Flame resistance – Glow wire test
750 °C according
to EN 60695-2-11
– – – Glow wire test
750 °C according
to EN 60695-2-11
Flammability to UL94 – V2 – – – –
Analog devices Z-MG/VA-250 Z-MG/VA-500 Z-MG/AA-10 Z-MG/AA-40
Electrical
Rated voltage Un V AC 250 500 – –
Rated current In A – – 10 40
Input signal Symmetrical, sinusoidal, harmonic factor 1.11
Rated frequency Hz 50 50 50 50
Operating frequency Hz 45 - 65 45 - 65 45 - 65 45 - 65
Measuring accuracy class 1.5 1.5 1.5 1.5
Measuring range 0 - Un 0 - Un 0 - In 0 - In
Intrinsic consumption VA < 3 < 3 < 1.1 < 1.1
Measuring range overshoot
Continuous 1.2 x Un 1.2 x Un 1.2 x In 1.2 x I n
Momentary 2 x U n/5 s 2 x Un/5 s 10 x In/5 s 10 x In/5 s
Rated insulation voltage kV 0.6 0.6 0.6 0.6
Test voltage 50 Hz/1 min. kV 2 2 2 2
Mechanical
Standard front dimension mm 45 45 45 45
Size of device base mm 89 89 89 89
Built-in width mm 70 70 70 70
Weight kg 0.13 0.13 0.13 0.13
Mounting Quick attachment for top-hat rail IEC/EN 60715
Degree of protection when fitted IP50 IP50 IP50 IP50
Terminals top and bottom Lift terminals Lift terminals Lift terminals Lift terminals
Terminal capacity mm 2 4 4 4 8
Tightening torque of terminal screws Nm 1 1 1 1.8
Admissible relative humidity % 65 65 65 65
Temperature range °C -25 - +50 -25 - +50 -25 - +50 -25 - +50
Flammability classification according to UL94 V1 V1 V1 V1
KT…, V-M…, STB-M…, Z-MG
